Speed Idle Roll Law Optimization in a Ring Rolling Process

Abstract:

Ring Rolling is a complex hot forming process where different rolls are involved in the production of seamless rings characterized by extreme dimensions (i.e. external diameter higher more than 1m). Because each roll can be independently controlled from the other ones different speed laws must be set; usually, in the industrial environment, a milling curve is introduced to monitor the shape of the workpiece during the deformation in order to ensure a correct ring production. In former works the authors focused their attention on the influence of different milling curves for an industrial case and the results underlined that a ring produced with a good quality and lower loads and energy could be obtained imposing a linearly descending trend to the Idle roll speed law. However different approaches could be used in order to evaluate the mentioned speed law.In this work the authors enhanced the knowledge about the optimization of the Idle roll speed law: different Idle roll speed laws were designed and simulated and the results were compared in order to identify the best speed law that guarantees a good quality ring with lower loads and energy required for manufacturing.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 248-253
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.248
• Online since: July 2015
• Authors: Luca Giorleo*, Elisabetta Ceretti, Claudio Giardini
• Keywords: FE Modeling, Idle Roll, Milling Curve, Ring Rolling Process

References

[1] H. Lin, Z. Z Zhi., The extremum parameters in ring rolling, Journal of Materials Processing Technology. 69 (1997) 273-276.

DOI: 10.1016/s0924-0136(97)00029-0

[2] Yan F.L., Hua L., Wu Y.Q., Planning feed speed in cold ring rolling, International Journal of Machine Tools & Manufacture. 47 (2007) 1695-1701.

DOI: 10.1016/j.ijmachtools.2007.01.009

[3] X. Han, L. Hua, Effect of friction coefficient on combined radial and axial ring rolling process, Tribology International 73 (2014) 117-127.

DOI: 10.1016/j.triboint.2014.01.009

[4] Anjami N., Basti A., Investigation of rolls size effects on hot rolling process by coupled thermo-mechanical 3D-FEA. Journal of Material Processing Technologies. 210 (2010) 1364-1377.

DOI: 10.1016/j.jmatprotec.2010.03.026

[5] X. Luo, L. Li, W. Xu, Y. Zhu, Effect of driver roll rotational speed on hot ring rolling of AZ31 magnesium alloy, Journal of Magnesium and Alloy. 2 (2014) 154-158.

DOI: 10.1016/j.jma.2014.05.003

[6] C. Wang, T. van den Boogard, E. Omerspahic, V. Recina, B. Geijselaers, Influence of feed rate on damage development in hot ring rolling, Procedia Engineering 81 (2014) 292-297.

DOI: 10.1016/j.proeng.2014.09.166

[7] Giorleo L., Ceretti E., Giardini C., Energy consumption reduction in Ring Rolling processes: A FEM analysis, International Journal of Mechanical Sciences. 74 (2013) 55-64.

DOI: 10.1016/j.ijmecsci.2013.04.008

[8] L. Guo, H. Yang, Towards a steady forming condition for radial-axial ring rolling, International Journal of Mechanical Sciences 53 (2011) 286-299.

DOI: 10.1016/j.ijmecsci.2011.01.010

[9] W. Xu, Q. Wang, X. Zhou, X. Yang, Quantitative design methodology for flat ring rolling process, Procedia Engineering 81 (2014) 280-285.

DOI: 10.1016/j.proeng.2014.09.164

[10] L. Giorleo, E. Ceretti, C. Giardini, Milling curves influence in Ring Rolling processes, Key Engineering Materials 622-623 (2014) 956-963.

DOI: 10.4028/www.scientific.net/kem.622-623.956

[11] L. Giorleo, C. Giardini, E. Ceretti, Validation of hot ring rolling industrial process 3D simulation, International Journal of Material Forming 6 (2013) 145–152.

DOI: 10.1007/s12289-011-1056-5
