Analyzing the Electrical Pulses Occurring during EDM of Non-Conductive Si₃N₄ Ceramics

Abstract:

With the help of an Assisting Electrode (AE), non-conductive ceramics can be machined using Electrical Discharge Machining (EDM) process. The AE helps start the EDM process and the intrinsic conductive layer (ICL) ensures that the electrical contact between the workpiece and the generator is maintained. However, the understanding of EDM process of non-conductive ceramics is limited due to the typical characteristic of the process: the geometric dimension of the discharge region is limited to few micrometers and the duration of the dielectric discharge is in the range of few microseconds making it difficult to directly observe the spark and the associated crater formation phenomenon. Analyzing the electrical signals during the EDM process could provide an insight of the process. This paper presents a study on analyzing the electric pulses occurring during the EDM process of a conductive workpiece (copper) and a non-conductive workpiece (Si₃N₄ ceramics). Typical pulses occurring during the EDM of a metal and a non-conductive ceramics are identified with the signal recorded at a sampling rate of 2.5 GS/s. Sampling rate of 25 MS/s is used to monitor the pulses occurring while machining a hole with depth of 1 mm. The pulses during EDM of non-conductive materials are significantly different than those during EDM of metals. Four most outstanding differences have been identified in terms of the ringing behavior of the voltage signal, the recharge time required to reach the set value of open voltage, the presence of the reverse current and the value of the peak current detected in case of Si₃N₄. The pulses monitored with lower sampling frequency was characterized and discriminated into sparks, arcs and short circuits. The percentage of the discriminated pulses for varying machining depth of the test structure has been presented.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 659-664
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.659
• Online since: July 2015
• Authors: Nirdesh Ojha*, Florian Zeller, Claas Mueller, Holger Reinecke
• Keywords: Si₃N₄, Current, EDM, Electrical Signal, Non-Conductive Ceramics, Pulse, Voltage

References

[1] N. Mohri, Y. Fukuzawa, T. Tani, N. Saito, and K. Furutani, Assisting Electrode Method for Machining Insulating Ceramics, CIRP Ann. - Manuf. Technol., vol. 45, no. 1, p.201–204, (1996).

DOI: 10.1016/s0007-8506(07)63047-9

[2] N. Ojha, T. Hösel, C. Müller, and H. Reinecke, Characterization of the conductive layer formed during µ-electric discharge machining of non-conductive ceramics, in Processing and Properties of Advanced Ceramics and Composites V, vol. 240, 2013, p.105.

DOI: 10.1002/9781118744109.ch12

[3] C. C. Kao and A. J. Shih, Sub-nanosecond monitoring of micro-hole electrical discharge machining pulses and modeling of discharge ringing, Int. J. Mach. Tools Manuf., vol. 46, no. 15, p.1996–2008, Dec. (2006).

DOI: 10.1016/j.ijmachtools.2006.01.008

[4] A. Descoeudres, C. Hollenstein, G. Wälder, and R. Perez, Time-resolved imaging and spatially-resolved spectroscopy of electrical discharge machining plasma, J. Phys. D. Appl. Phys., vol. 38, no. 22, p.4066–4073, Nov. (2005).

DOI: 10.1088/0022-3727/38/22/009

[5] A. Schubert, H. Zeidler, N. Wolf, and M. Hackert, Micro Electro Discharge Machining of Electrically Nonconductive Ceramics, Physics (College. Park. Md)., vol. 1308, p.1303–1308, (2011).

DOI: 10.1063/1.3589696

[6] N. Ojha, C. Mueller, and H. Reinecke, Parametric Analysis of µ-Electric Discharge Machining of non-conductive Si3N4, Appl. Mech. Mater., vol. 564, p.560–565, (2014).

DOI: 10.4028/www.scientific.net/amm.564.560

[7] K. Takahata and Y. B. Gianchandani, Batch mode micro-electro-discharge machining, J. Microelectromechanical Syst., vol. 11, no. 2, p.102–110, Apr. (2002).

DOI: 10.1109/84.993444

[8] D. F. Dauw and R. Snaeys, Adaptive Control Optimization of the Electro-Discharge Machining Process By Real Time Pulse Detection, Adv. Manuf. Process., vol. 1, no. 1, p.45–81, Jan. (1986).

DOI: 10.1080/10426918608953157
