Determination of Mechanical Properties of Non-Conventional Reinforcement

Abstract:

Mechanical tests of samples of basalt and textile glass reinforcement were performed within the solution of the research project GAČR 13-12676S and SGS14/171/OHK1/2T/31. These tests were carried out because of the need to establish elementary mechanical quantities that are tensile strength and modulus of elasticity of non-conventional reinforcement. Both of these quantities are required for further modeling of structures and for designing of the elements made from textile reinforced concrete (TRC) as not being provided by reinforcement manufacturers. The tests were carried out on a total of 12 samples of reinforcement where the first 6 samples were made from textile glass reinforcement (AR-G = Alkali-Resistant Glass) and the remaining 6 samples were prepared from basalt reinforcement. The filament sheaf fibers called roving was used for the production of test specimens.

You might also be interested in these eBooks

Mechanical Properties of Materials from Nano to Micro/Meso-Scale

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 662)

Pages:

249-252

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.662.249

Citation:

Cite this paper

Online since:

September 2015

Authors:

Tomáš Bittner*, Petr Bouška, Michaela Kostelecká, Šárka Nenadálová, Milan Rydval, Miroslav Vokáč

Keywords:

Basalt Reinforcement, Modulus of Elasticity, Non-Conventional Reinforcement, Tensile Strength, Textile Glass Reinforcement

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] ČSN EN ISO 13934-1 Textiles – Tensile properties of fabrics – Part 1: Determination of maximum force and elongation at maximum force using the strip method.

DOI: 10.3403/01736255

Google Scholar

[2] ČSN EN ISO 13934-2 Textiles – Tensile properties of fabrics – Part 2: Determination of maximum force at maximum force using the grab method.

DOI: 10.3403/01736243u

Google Scholar

[3] Information on http: /www. sciencedirect. com/science/article/pii/S0141029607003227.

Google Scholar

[4] Kießling/Matthes, Textil - Fachwörterbuch, Berlin (1993).

Google Scholar

[5] High-Performance Structural Fibers for Advanced Polymer Matrix Composites, The National Academies Press, (2005).

Google Scholar

[6] T. Vlach, L. Laiblova, A. Chira, M. Novotna, C. Fiala, M. Zenisek, P. Hajek. Comparison of Different Methods for Determination of Modulus of Elasticity of Composite Reinforcement Produced from Roving. 11th International Conference on Special Concrete and Composites. Trans Tech Publications Ltd, Switzerland (2014).

DOI: 10.4028/www.scientific.net/amr.1054.104

Google Scholar
