Structure and Dielectric Properties of Ce and Ca Co-Doped BaTiO₃ Ceramics

Abstract:

Structure and dielectric properties of 5 % Ce and Ca co-doped BaTiO₃ ceramics were investigated. The site occupations and valence states were studied using XRD, Raman spectroscopy, SEM, EPR and dielectric measurements. The Ba/Ti ratio has dramatic effects on ceramic structure and properties. Two single-phase ceramics with Ba/Ti = 1 and 0.937 have tetragonal and cubic structure, showing diffuse phase transition and first-order phase transition behaviors, respectively. The former exhibit the site occupations of mixed Ca²⁺/Ce³⁺ at Ba sites and Ca²⁺/Ce⁴⁺ at Ti sites. Ce ions have priority over Ca²⁺ ions in entering Ti sites as Ce⁴⁺ when co-doping in BaTiO₃, which will impede Ca²⁺ ions to be incorporated completely into Ti sites.

• Periodical: Key Engineering Materials (Volume 680)
• Pages: 184-188
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.680.184
• Online since: February 2016
• Authors: Da Yong Lu*, Dan Dan Han, Qiao Li Liu, Yan Dong Wang, Xiu Yun Sun
• Keywords: Defect Complexes, Dielectric Properties, Perovskites, Site Occupation

References

[1] D.Y. Lu, Y. Yue, X.Y. Sun, Novel X7R BaTiO3 ceramics co-doped with La3+ and Ca2+ ions, J. Alloys Compd. 586 (2014) 136–141.

DOI: 10.1016/j.jallcom.2013.10.055

[2] J.H. Hwang, Y.H. Han, Electric properties of cerium-doped BaTiO3, J. Am. Ceram. Soc. 84 (2001) 1750–1754.

[3] M. Cernea, O. Monnereau, P. Llewellyn, L. Tortet, C. Galassi, Sol-gel synthesis and characterization of Ce-doped BaTiO3 ceramics, J. Eur. Ceram. Soc. 26 (2006) 3241–3246.

DOI: 10.1016/j.jeurceramsoc.2005.09.039

[4] D.Y. Lu, D.D. Han, X.Y. Sun, X.L. Zhuang, Y.F. Zhang, Raman evidence for Ba-Site Ce3+ in BaTiO3, Jpn. J. Appl. Phys. 52 (2013) 111501.

[5] A. Chen, Y. Zhi, J. Zhi, P.M. Vilarinho, J.L. Baptista, Synthesis and characterization of Ba(Ti1-xCex)O3 ceramics, J. Euro. Ceram. Soc. 17 (1997) 1217–1221.

DOI: 10.1016/s0955-2219(96)00220-8

[6] D.Y. Lu, D.D. Han, In-situ diffuse phase transition at the Curie point of BaTiO3 induced by amphoteric Ce3+/Ce4+ ions, Ceram. Int. 39 (2013) 9727–9730.

DOI: 10.1016/j.ceramint.2013.04.057

[7] D. Makovec, Z. Samardzija, D. Kolar, Solid solubility of cerium in BaTiO3, J. Solid State Chem. 123 (1996) 30–38.

DOI: 10.1006/jssc.1996.0148

[8] R. K. Zheng, J. Wang, X. G. Tang, Y. Wang, H. L. W. Chan, C. L. Choy, X. G. Li, Effects of Ca doping on the Curie temperature, structural, dielectric, and elastic properties of Ba0. 4Sr0. 6−xCaxTiO3 (0 ≤ x ≤ 0. 3) perovskites, J. Appl. Phys. 98 (2005).

DOI: 10.1063/1.2112175

[9] Z. Q. Zhuang, M. P. Hamer, D. M. Smyth, The effect of octahedrally-coordinated calcium on the ferroelectric transition of BaTiO3, Mater. Res. Bull. 22 (1987) 1329-1335.

DOI: 10.1016/0025-5408(87)90296-0

[10] L. Zhang, O. P. Thakur, A. Feteira, G. M. Keith, A. G. Mould, D. C. Sinclair, A. R. West, Comment on the use of calcium as a dopant in X8R BaTiO3-based ceramics, Appl. Phys. Lett. 90 (2007) 142914.

DOI: 10.1063/1.2720305

[11] R.D. Shannon, Revised effective ionic radii and systematic studies of interatomic distances in halides and chalcogenides, Acta Cryst. A 32 (1976) 751–767.

DOI: 10.1107/s0567739476001551

[12] D.Y. Lu, M. Sugano, M. Toda, High-permittivity double rare earth-doped barium titanate ceramics with diffuse phase transition, J. Am. Ceram. Soc. 89 (2006) 3112–3123.

DOI: 10.1111/j.1551-2916.2006.00893.x

[13] D.Y. Lu, S.Z. Cui, Defects characterisation of Dy-doped BaTiO3 ceramics via electron paramagnetic resonance, J. Eur. Ceram. Soc. 34 (2014) 2217–2227.

DOI: 10.1016/j.jeurceramsoc.2014.02.003
