In Situ Measurements of Raman Spectra for PLZT Ceramics under Compressive Stresses

Abstract:

A lanthanum doped lead zirconate titanate (PLZT) ceramic specimen was prepared by the conventional solid state reaction method. The crystal phase and morphology of the PLZT specimen were characterized by XRD and SEM techniques, with the hysteresis loop by RT6000HVS system. The compressive stress was applied to the PLZT specimen through the microtest mechanical loading device. In-situ Raman spectra focused on a fixed grain under various compressive stresses were recorded for different polarization directions of the scattered light. The effects of stresses on the Raman spectra and the intensity ratio between the E+B1 and E(2TO) modes are discussed.

• Periodical: Key Engineering Materials (Volume 680)
• Pages: 25-29
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.680.25
• Online since: February 2016
• Authors: Li Ping Liang, Xuan Cheng, Ying Zhang*
• Keywords: Compressive Stress, Domain Switching, Ferroelectric Ceramic, Raman Spectrum

References

[1] W. Yang, Mechatronic Reliability, first ed., Tsinghua University, Beijing, (2002).

[2] L.I. Dontzova, N.A. Tikhomirova, L.A. Shuvalov, Investigation of domain-structure and switching processes in ferroelectrics by the liquid-crystal method, Ferroelectrics. 97 (1989) 87-124.

DOI: 10.1080/00150198908018085

[3] Z.K. Xu, In situ TEM study of electric field-induced microcracking in piezoelectric single crystals, Mat. Sci. Eng. B-solid. 99(1-3) (2003) 106-111.

DOI: 10.1016/s0921-5107(02)00430-0

[4] M. Liu, K.J. Hsia, M.R. Sardela, In situ X-Ray diffraction study of electric-field-induced domain switching and phase transition in PZT-5H. J. Am. Ceram. Soc, 88 (2005) 210-215.

DOI: 10.1111/j.1551-2916.2004.00048.x

[5] B.Y. Zhang, F.M. Jiang, Y. Yang, Electron acoustic imaging of BaTiO3 single crystals, J. Appl. Phys. 80(3) (1996) 1916-(1918).

[6] V.V. Shvartsman, A.L. Kholkin, C. Verdier, Investigation of fatigue mechanism in ferroelectric ceramic via piezoresponse force microscopy, J. Eur. Ceram. Soc. 25(12) (2005) 2559-2561.

DOI: 10.1016/j.jeurceramsoc.2005.03.100

[7] S. Zhang, X. Cheng, Y. Zhang, Recent progress on observations of domain switching in ferroelectric ceramics, J. Func. Mat. 36(1) (2005) 15-18.

[8] Y. Zhang, Z.W. Chen, X. Cheng, In usitu XRD investigation of domain switching in ferroelectric ceramics PLZT during an electric fatigue process, Acta. Metall. Sin. 40(12) (2004) 1299-1304.

[9] Y. Zhang, X. Cheng, S. Zhang, In-situ Raman spectroscopic study of domain switching of PLZT ceramics, Appl. Phys. A. 89(3) (2007) 685-693.

DOI: 10.1007/s00339-007-4149-8

[10] M. Cazayous, D. Malka, D. Lebeugle, Electric field effect on BiFeO3 single crystal investigated by Raman spectroscopy, Appl. Phys. Lett. 91(7) (2007) 071910-071913.

DOI: 10.1063/1.2771380

[11] T. Sakashita, H. Chazono, G. Pezzotti, Quantitative analysis of domain texture in polycrystalline barium titanate by polarized Raman microprobe spectroscopy, J. Appl. Phys. 102(12) (2007) 124106.

DOI: 10.1063/1.2822464

[12] M. Deluca, T. Sakashita, C. Galassi, Investigation of local orientation and stress analysis of PZT-based materials using micro-probe polarized Raman spectroscopy, J. Eur. Ceram. Soc. 26(12) (2006) 2337-2344.

DOI: 10.1016/j.jeurceramsoc.2005.04.016

[13] Q.Y. Zhuang, X. Cheng, S. Zhang, In-situ Raman measurements of PZT under a stress field, J. Func. Mat. 45(4) (2014) 4100-4103.
