Study on Torsional Excitation of Vibration Stress Relief Based on Lateral and Torsional Coupling

Abstract:

According to the engineering application of vibration stress relief (VSR) based on lateral and torsional coupling, the controlled single-phase series motor is used to create alternating electromagnetic torque, which excites the torsional vibration of the shaft. After adding the expression of the electromagnetic torque to the multi-dof dynamic equation of the lateral and torsional coupling, the dynamic response of lateral and torsional coupling can be calculated. The result has value in the application of VSR based on lateral and torsional coupling.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 221-226
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.221
• Online since: May 2016
• Authors: Yuan Xing Huang*, Gan Wei Cai, Yong Wen Zhang
• Keywords: Lateral Coupling, Torsional Coupling, Torsional Excitation, VSR

References

[1] Yilong Yu, The simulating research on active control to the low frequency vibration of a large rotor shatf system with multi-support, MA thesis, TianJin University, 2005. (in Chinese).

[2] Jianping Zhang, Experimental investigation on torsional vibration measurement and control of rotor shaft system, MA thesis, TianJin University, 2007. (in Chinese).

[3] Xingxing Wu, The design and experimental deviee study of torsional vibration damper for diesel shafting, MA thesis, Wuhan University of Technology, 2009. (in Chinese).

[4] Yong Zhang, Research on the torsional and coupling flexural-torsional vibration of the turbogenerator set , Ph. D Thesis, Qinghua University, 1997. (in Chinese).

[5] Juanhua Liu, Research on torsional vibration of the shafts of large turbo-generator sets, Ph. D Thesis, Huazhong University of Science and Technology, 2006. (in Chinese).

[6] Ruiguang Geng, Hongtian Zhang, Huiwen Wang, Development of test bed of controllable torsional excitation for shafting of IC engine, Chinese Internal Combustion Engine Engineering. 31(3) (2010) 105-108. (in Chinese).

[7] Bo Pan, Jing Sun, Lifen Lou, Dynamic modeling, simulation and test verification for a drive mechanism of a generator, Journal of Vibration and Shock. 30(5) (2011) 236-240, 266. (in Chinese).

[8] Weidong Guo, Wengang Gu, Xialing Zhang. The method of compensating division error in shafts torsional vibration measurement and implementation with program, Machine Design and Research. 23(2) (2007) 88-89, 94. (in Chinese).

[9] Ittapana Perera, Theoretical and experiment study of coupled torsional-lateral vibrations in rotor dynamics, MA thesis, University of Calgary, (1998).

[10] Yuming Liu, Design and research on the control system of household blender, MA thesis, Harbin Institute of Technology, 2008. (in Chinese).

[11] Bangchun Wen, Jialiu Gu, Songbo Xia, etc, Advanced rotordynamics-theory, technology and application, China Machine Press, Beijing, 1998. (in Chinese).

[12] Rao, J.S., T.N. Shiau and J.R. Chang, Theoretical analysis of lateral response due to torsional excitation of geared rotors, Mechanism and Machine Theory. 33(6) (1998) 761-783.

DOI: 10.1016/s0094-114x(97)00056-6

[13] Mohiuddin M A, Khulief Y A, Coupled bending torsional vibration of rotors using finite element, Journal of Sound and Vibration. 223(2) (1999) 297-316.

DOI: 10.1006/jsvi.1998.2095

[14] A.S. Das, J.K. Dutt, K. Ray, Active control of coupled flexural-torsional vibration in a flexible rotor-bearing system using electromagnetic actuator, International Journal of Non-Linear Mechanics. 46(2011) 1093-1109.

DOI: 10.1016/j.ijnonlinmec.2011.03.005
