Structural Design and Improvement of Spindle in Five-Axis Wood Engraving Machine

Abstract:

In the wood engraving industry, the double swing motor spindle or the double rotation motor spindle is often used as the spindle of five-axis wood engraving machine to achieve three-dimensional sculpture. However, the rough and motor spindle may interfere with each other during machining. Hence, many small regions of rough cannot be machined. To solve this problem, an anthropomorphic double-swing-head mechanism is designed. Instead of motor spindle, the designed mechanism is used as spindle of five-axis wood engraving machine. The level of automation and machining scope of the machine are improved. The workload of subsequent artificial modification is reduced. Then, the machining efficiency and quality of wood products are enhanced, and their production costs are reduced.
