Geometrical Modeling of Tool-Workpiece Contact Zone and Chip Formation in Finish Ball End Milling Process with Tool Inclination Angles

Abstract:

The tool-workpiece contact zone is an important issue in the ball end milling process. This paper investigated the effects of tool inclination angles on the tool-workpiece contact zone, and variations of the cutting section area and perimeter with the increasing tilt and lead angles were also analyzed by geometrical modeling and measurement method for ball end milling process. The appropriate tool inclination angles, which could avoid the extrusion and friction between tool tip and the uncut materials, shorten the loading time on the cutting flute, and decrease the maximum cutting forces, could be preferentially selected according to the distribution characteristics of the tool-workpiece contact zone and the variations of the cutting section area and perimeter corresponding to various tool postures.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 788-794
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.788
• Online since: May 2016
• Authors: Xiao Xiao Chen*, Jun Zhao
• Keywords: Cutting Section, Geometrical Modeling, Inclination Angles, Tool-Workpiece Contact Zone

References

[1] S. Wojciechowski: Int. J. Mach. Tools Manuf. Vol. 89 (2015), p.110.

[2] S. Wojciechowski, P. Twardowski, M. Pelic: Procedia CIRP Vol. 14 (2014), p.113.

[3] K.D. Bouzakis, P. Aichouh, K. Efstathiou: Int. J. Mach. Tools Manuf. Vol. 43 (2003), p.499.

[4] X.G. Liang, Z.Q. Yao: Computer-Aided Design Vol. 43 (2011), p.971.

[5] M. Cosma: The International Conference of The Carpathian Euro-Region Specialists in Industrial Systems. (2006), p.45.

[6] X.X. Chen, J. Zhao, S. Liu, Y.W. Dong, F.Z. Wang: Proc. IMechE, Part B: J. Engineering Manufacture. Vol. 228 (2014), p.337.

[7] E. Budak, E. Ozturk, L.T. Tunc: CIRP - Manufact Technol. Vol. 58 (2009), p.347.

[8] E. Budak, E. Ozlu: CIRP - Manufact Technol. Vol. 57 (2008), p.97.
