Superficial Residual Stresses in Face-Milling the 17-4PH Stainless Steel at Various Feed Rates

Abstract:

17-4PH stainless steel is a widely used martensitic precipitation hardening stainless steel, and it is a typical difficult-to-cut material. Residual stress is an important part of the surface integrity. In this paper, superficial residual stress tests of face-milling the 17-4PH stainless steel were carried out at 0.1~0.3 mm/tooth with TiAlN coated carbide inserts. The effects of feed rate on the superficial residual stresses at various cutting speeds were studied. It was found that the residual stresses on the machined surface were very sensitive to the feed rate. The superficial residual stresses at the directions of parallel to and normal to the feed direction both remained compressive and changed obviously in higher compressive direction along with the feed rate. The burnishing effect determined by the cutting force was found to be the primary reason of the residual compressive stresses on the machined surface. The suitable cutting parameters were recommended according to the superficial residual stresses.

You might also be interested in these eBooks

Advanced Materials and Manufacturing Technology II

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 693)

Pages:

922-927

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.693.922

Citation:

Cite this paper

Online since:

May 2016

Authors:

Guo Liang Liu*, Chuan Zhen Huang, Bin Zou, Jun Wang, Xiang Yu Wang, Han Lian Liu

Keywords:

17-4PH Stainless Steel, Burnishing Effect, High-Speed Face-Milling, Superficial Residual Stress

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] W.T. Chien and C.S. Tsai: Journal of Materials Processing Technology. 140 (2003), pp.340-345.

Google Scholar

[2] Z. Klim, E. Ennajimi and M. Balazinski et al: Wear. 195 (1996), pp.206-213.

Google Scholar

[3] L. Jia: Tool Engineering. 44(1) (2010), pp.63-66.

Google Scholar

[4] C. Cao, Z. Liu and Q. Lin: Tool Engineering. 45(5) (2011), pp.13-17.

Google Scholar

[5] B.R. Sridhar, G. Devananda and K. Ramachandra et al: Journal of Materials Processing Technology. 139(1) (2003), pp.628-634.

Google Scholar

[6] Z.T. Tang, Z.Q. Liu and Y.Z. Pan et al: Journal of Materials Processing Technology. 209(9) (2009), pp.4502-4508.

Google Scholar

[7] X. Ai: High speed machining technology (National Defense Industry Press, China 2003).

Google Scholar

[8] Z.T. Tang, Z.Q. Liu and X. Ai: China Mechanical Engineering. 19(6)(2008), pp.699-703.

Google Scholar

[9] T.I. El-Wardany, H.A. Kishawy and M.A. Elbestawi: Journal of manufacturing science and engineering. 122 (2000), pp.632-641.

Google Scholar

[10] A.R.C. Sharman, J.I. Hughes and K. Ridgway: Journal of Materials Processing Technology. 173 (2006), p.359–367.

Google Scholar
