The Design of Turn-Mill Process Planning for Mass Customization Wheel Rim

Abstract:

Targeted at numerical control machining process of mass customization vehicle wheel rim revolving body parts and its fixture planning problem, using the dot product method between the unit normal vector of the feature facet, it was provide to distinguish the main direction of machining surface, machining position of workpiece was determined, and NC machining process of integrated procedure was designed. The loaded and taken out of the wheel rim workpiece were analyzed according to the two-dimensional plane clamping method, the clamping point position of wheel rim workpiece can be determined. Using the principle of planar mechanism kinematic to analyze one’s claw of turn-mill fixture kinematics trace, so that a quick clamping structure can reduce the cylinder stroke was designed. This fixture device was convenient and reliable.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 936-943
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.936
• Online since: May 2016
• Authors: Gou Zheng Zhang*, Yuan Zhi Zhou, Jiang Han, L. Xu
• Keywords: Feature Facet, Turn-Mill Compound Fixture Clamping Mechanism, Turn-Mill Process Planning, Unit Normal Vector

References

[1] Kumar M V S, Janardhana R, Rao C S P．Simultaneous scheduling of machines and vehicles in an FMS environment with alternative routing[J]. The International Journal of Advanced Manufacturing Technology, 2011, 53( 1- 4) : 339- 351.

DOI: 10.1007/s00170-010-2820-2

[2] SERTAC P, JOSHUA D S. A review of computer-aided fixture design with respect to information support requirements[J]. International Journal of Production Research, 2008, 46(4): 929-947.

DOI: 10.1080/00207540600865386

[3] DEB K. An efficient constraint handling method for genetic algorithms[J]. Computer Methods in Applied Mechanics and Engineering, 2000, 186(2): 311-338.

DOI: 10.1016/s0045-7825(99)00389-8

[4] HARIRI A, RASTEGAR R, NAVI K, et al. Cellular learning automata based evolutionary computing (CLA-EC) for intrinsic hardware evolution[C]/Evolvable Hardware, 2005. Proceedings. 2005 NASA/Do D Conference on. IEEE, 2005: 294-297.

DOI: 10.1109/eh.2005.12

[5] DU S C, LÜ J, XI L F. A robust approach for root causes identification in machining processes using hybrid learning algorithm and engineering knowledge[J]. Journalof Intelligent Manufacturing, 2012, 23: 1833-1847.

DOI: 10.1007/s10845-010-0498-9

[6] Sertac P, Joshua D S. A review of computer-aided fixture design with respect to information support requirements. International Journal of Production Research [J]. 2008, 46（4）: 929-947.

DOI: 10.1080/00207540600865386

[7] Wang H, Rong Y M, et al. Computer aided fixture design: Recent research and trends [J]. Computer aided design, 2010, 42(12): 1085-1094.

DOI: 10.1016/j.cad.2010.07.003
