The Influence of Tool Geometric Parameters on the Reliability of Deep Cryogenic High Speed Steel Taps

Abstract:

The selection of geometric parameters of cryogenic tap has a direct effect on the reliability of tools and the precision of processed workpiece. Based on nonsubstitute Type-I Censoring Life Tests, a mathematical model in dynamic reliability of cryogenic tap is built, and the change of its reliability is explored. Combined with cutting tool life expansion equation, the effects of geometric parameters on wear life are presented. The results show that of the geometric parameters, rake angle taps in its effect on reliability with the increase in machining time and impact loading action, thus the quality of rake angle should be controlled directly or indirectly so as to reduce its influence on reliability of cutting tool, which can ultimately improve the reliability of cutting tool and the precision of processed workpiece. Meanwhile, the proposed method provides a theoretical basis for improvements of the reliability of tool system.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 959-964
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.959
• Online since: May 2016
• Authors: Shao Hua Zhang*, Xian Guo Yan, Hong Guo, Fei Peng, Jun Ji Li, Zhi Yang Feng
• Keywords: Cryogenic Tap, Flank Wear, Geometric Parameters, Reliability

References

[1] R. Han, Y. Tang, L. Cheng, New Efficient Tap by Precision Tapping for Difficult-to-Machine Material in Aerospace Industry, Aeronautical Manufacturing Technology. 2008(03): 14-18.

[2] M. Wang, C. Duan, Micro Structure and Mechanical Properties of High Speed Steel after Cyclic Cryogenic Treatment, Hot Treatment of Mantles. 2008(03): 90-93.

[3] X. Li, S. Li, Z. Yuan, Effect of Cryogenic Treatment on Mechanical Properties of High-Speed Steel at High Temperature and Room Temperature, Journal of Gansu University of Technology. 2001(03): 19-22.

[4] B. Gu, J. Cong, Property Improvement and Microstructure Transformation of High-Speed Steel due to Deep Cryogenic Treatment, Journal of Dalian University of Technology. 1997(03): 43-47.

[5] Š. Sanja; C. Franjo; P. Peter, Influence of deep cryogenic treatment of high speed steel substrate on TiAlN coating properties, Werkstofftech. 2013, 44(12).

DOI: 10.1002/mawe.201300168

[6] Y. Dong, X. Ling, Z. Li, Effect of Cryogenic Treatment on Red Hardness and Wear Resistance of High Speed Steels, Heat Treatment of Metals. 1997(09): 13-15.

[7] H. Zhang, X. Yan, Influences of Cryogenic Treatment on High Speed Tap Wear, Manufacturing Technology & Machine Tool. 2014(05): 108-111.

[8] G. Li, X. Yan, N. Peng, Research Review about Effect of Deep Cryogenic Treatment on Residual Stress of Workpiece, Hot Working Technology. 2013(20): 19-23.

[9] A. Liu, H. Shen, J. Kruth, Mechanism of the tool flank wear influenced by the vibration characteristics of the toolhoblder system in high speed milling, Chinese Journal of Mechanical Engineering. 2008(04): 63-68.

DOI: 10.3901/jme.2008.04.063

[10] X. Ai, Z. LI, J. Deng, Optimization of Machining Variables Taking Cutting Tool Reliability into Consideration, Chinese Journal of Mechanical Engineering. 1995(06): 6-10.

[11] C. Zhang, X. Wen, X. Chen, A Comprehensive Review of Accelerated Life Testing, Journal of China Ordnance. 2005(02): 213-219.

[12] X. Wang, Y. Zhang, H. Li, Dynamic Reliability Sensitivity of Cemented Carbide Cutting Tool, Chinese Journal of Mechanical Engineering. 2014(01): 79-85.

DOI: 10.3901/cjme.2014.01.079

[13] X. Ye, H. Liang, G. Zhai, Discussion on dynamic reliability tolerance design technology of electromagnetic relay, Journal of Zhejiang University. 2007(03): 439-443.

DOI: 10.1631/jzus.2007.a0439
