Ultrasonic Vibration Turning of Stainless Slender Shaft: Investigation on Run-Out of Two Clamping Methods

Abstract:

Slender shaft is of high slenderness ratio and bad rigidity. The factors, for example, cutting force, cutting heat, vibration and so on, which are produced in the processing, will affect directly the size precision of workpieces. In this research, slender shaft is 304 stainless steel bar, with length of 450mm and diameter of 10mm. In order to resolve the problem of slender shaft machining with CNC slant bed lathe not configured with the follow-rest, a self-made follow-rest was developed. With both ends clamped processing mode, it is possible to use the CNC lathe turning slender shaft. Moreover, better effect of turning of slender shaft can be attained if ultrasonic vibration cutting technology is involved. After turning process is completed, size accuracy is checked to evaluate the effect of self-made follow-rest and both ends clamped processing mode. In this study, the experimental results show that quality of the slender shaft processing has been significantly improved with the use of self-made follow-rest and both ends clamped processing mode, which has definite effects on solving the practical problems of processing.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 990-995
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.990
• Online since: May 2016
• Authors: Xu Dong He*, Guo Qiang Guo, Kang Li, Ming Chen
• Keywords: Run-Out Detection, Slender Shaft, Turning, Ultrasonic Vibration Assisted Machining

References

[1] Han Rongdi, GuoJianliang, Simulation of size error in slender shaft turning with follow-rest [J], Journal of Nanjing University of Aeronautics &Astronautics, Vol. 37 (2005) 108-112.

[2] Nath C, Rahman M, Effect of machining parameters in ultrasonic vibration cutting [J], International Journal of Machine Tools and Manufacture. 48(2008) 965-974.

DOI: 10.1016/j.ijmachtools.2008.01.013

[3] Shi, D. Gindy, N. N, Development of an online machining process monitoring system: Application in hard turning [J], Sensors and Actuators A: Physical. 135(2007) 405-414.

DOI: 10.1016/j.sna.2006.08.011

[4] Ahmed, N. Mitrofanov, A. V. Babitsky, V. I, 3D finite element analysis of ultrasonically assisted turning [J], Computational Materials Science. 39(2007) 149-154.

DOI: 10.1016/j.commatsci.2005.12.045

[5] Marsh E R, Schaut A J, Measurement and simulation of regenerative chatter in diamond turning [J], Precision engineering. 22(1998) 252-257.

DOI: 10.1016/s0141-6359(98)00020-8

[6] H. Li and C. Zhang: Mining Machinery, Vol. 40 (2012) No. 9, p.138.

[7] Srinivasa N, Ziegert J C, Prediction of thermally induced time-variant machine tool error maps using a Fuzzy ARTMAP neural network [J], Journal of manufacturing science and engineering. 119(1997) 623-630.

DOI: 10.1115/1.2831196

[8] Liu, Z. -Q, Repetitive measurement and compensation to improve workpiece machining accuracy [J], International Journal of Advanced Manufacturing Technology. 15 (1999) 85-89.

DOI: 10.1007/s001700050043

[9] L.J. Guo, Investigation on Turning of Slender Shaft [D], Harbin Institute of Technology, (2006).

[10] Zhao Haitao, Yang Jianguo, Tong Hengchao, Vibration turning of slender shaft and compensation control [J]. Journal of Shanghai Jiao Tong University (2005) 117-120.
