Experimental Research on Bearing Strength and Effect Laws for Woven GFRP Composite Laminates

Abstract:

Based on ASTM D 5961 standard, the double-shear bearing strength and effect laws for woven glass fiber/vinyl resin composite laminates are studied. By testing of various specimen, bearing chord stiffness line is properly determined according bearing stress range, and effect laws on bearing strength are analyzed when (±45)°/(0/90)°plies proportion and fastener torque get changed. The results show, with 40%~60% (±45)°plies proportion, the bearing strength and the offset bearing strength simultaneously reach to the high value region with small fluctuation. As fastener torque increases, bearing strength increasing trend gets slow while offset bearing strength first increases and then decreases.

• Periodical: Key Engineering Materials (Volume 705)
• Pages: 103-107
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.705.103
• Online since: August 2016
• Authors: Ling Liu*, Hua Dong Li, Zhi Yuan Mei
• Keywords: Bearing Strength, Double-Shear Joint, Fastener Torque, Plies Proportion, Woven GFRP

References

[1] WANG Huajuan, YANG Jie, LIU Xindong, et. al. Research on Affecting Factors of Mechanical Joining Strength of Composite Material[J]. Materials Review, 2007, (21): 438-440.

[2] ZHANG Shuang, WANG Dong, LI Zheng neng, et. al. Numerical calculation of damage accumulation and bearing strength experimental verification for composite single bolted joint[J]. Acta Materiae Compositae Sinica, 2006, 23(2): 163-168.

[3] LIU Jian chao, WANG Tie Jun, ZHANG Wei, et. al. Experimental Study on Pinned Joints Strength of Satin Carbon Fabric/Epoxy Composites[J]. Journal of Materials Engineering, 2005, 7: 51-54.

[4] Yunong Zhai, Dongsheng Li, Xiaoqiang Li, et. al. An experimental study on the effect of bolt-hole clearance and bolt torque on single-lap, countersunk composite joints[J]. Composite structures, 2015, 127: 411-419.

DOI: 10.1016/j.compstruct.2015.03.028

[5] YANG Xiankun, ZHENG Xitao, CHENG Li'nan, et. al. An engineering approach to predict the bearing strength of single-bolted double-lapped joints in composite laminate[J]. Acta Materiae Compositae Sinica, 2012, 29(6): 225-229.

[6] WANG Dan yong, WEN Wei dong, et. al. Experiments on damage failure test of single bolted joints in composite laminates[J]. Journal of Aerospace Power, 2008, 23(2): 286-292.

[7] Kyle C. Warren, Roberto A. Lopez-Anido, Jonathan Goering. Behavior of three-dimensional woven carbon composites in single-bolt bearing[J]. Composite structures, 2015, 127: 175-184.

DOI: 10.1016/j.compstruct.2015.03.022

[8] LIU Chang xi, ZHOU Zhen gong, ZHANG Bo ming, et. al. The Research on the Compressive Strength Test Method for Lamination Connecting Structure[J]. Development and Application of Materials, 2014, 29(2): 50-54.

[9] B. Vangrimde, R. Boukhili. Analysis of the bearing response test for polymer matrix composite laminates: bearing stiffness measurement and simulation[J]. Composite structures, 2002, 56: 359-374.

DOI: 10.1016/s0263-8223(02)00020-x

[10] ASTM D 5961. Standard test method for bearing response of polymer matrix composite laminates[S]. Am Soc Testing Mater (2013).

[11] Camanho P P, Bowron S, Matthews F L. Failure mechanisms in bolted FRP[J]. Reinforced Plastic Composites, 1998, 17(3): 205-233.

DOI: 10.1177/073168449801700302
