Experimental Study on Ignition and Combustion Characteristics of Fibre-Reinforced Phenolic Composite

Abstract:

The ignition and combustion characteristics of the fibre-reinforced phenolic composite were studied experimentally employing cone calorimeter. Various parameters, including the ignition time, the mass loss and mass loss rate (MLR), the heat release rate (HRR) and the concentration of the carbon dioxide and carbon monoxide were measured and presented. Linear correlations of the transformed ignition time (1/t_ig)^0.55 and 1/t_ig, the first and second peak MLR, the average MLR and the peak HRR with the heat flux were demonstrated. Based upon the correlations and theoretical analyses, flammability properties including the critical heat flux (CHF) and the minimum heat flux, the ignition temperature, the heat of gasification and the heat of combustion were calculated. The specimen with the thickness of 3 mm was prone to be thermally thin material. The peak concentration of the carbon dioxide increased with the heat flux. However, the peak concentration of the carbon monoxide declined with an increase in the applied heat flux.

• Periodical: Key Engineering Materials (Volume 707)
• Pages: 13-22
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.707.13
• Online since: September 2016
• Authors: Rui Yu Chen, Shou Xiang Lu*, Chang Hai Li, Siu Ming Lo
• Keywords: Combustion Characteristics, Cone Calorimeter, FRP, Ignition, Phenolic

References

[1] G. Duggan, Usage of ISO 5660 data in UK railway standards and fire safety cases, A One-Day Conference on Fire Hazards, Testing, Materials and Products. Shrewsbury, pp.1-8, 1997, Rapra Technology Ltd. UK.

[2] B. H. Chiam, Numerical simulation of a metro train fire, M.S. thesis, Department of Civil Engineering, University of Canterbury, Christchurch, New Zealand, (2005).

[3] H. Ingason, M. Kumm, D. Nilsson, A. Lönnermark, A. Claesson, Y. Z. Li et al, The METRO project, final report, Technical Report: SiST 2012: 8, Sweden: Mälardalen University Press, (2012).

[4] R. Chen, S. Lu, C. Li, Y. Ding, B. Zhang, S. Lo, Correlation analysis of heat flux and cone calorimeter test data of commercial flame-retardant ethylene-propylene-diene monomer (EPDM) rubber, Journal of Thermal Analysis and Calorimetry, 2015. Available: http: /link. springer. com/article/10. 1007/s10973-015-4900-x.

DOI: 10.1007/s10973-015-4900-x

[5] R. Chen, S. Lu, C. Li, M. Li, S. Lo, Characterization of thermal decomposition behavior of commercial flame-retardant ethylene-propylene-diene monomer (EPDM) rubber, Journal of Thermal Analysis and Calorimetry, 2015. Available: http: /link. springer. com/article/ 10. 1007/s10973-015-4701-2#page-1.

DOI: 10.1007/s10973-015-4701-2

[6] A. Mouritz, Z. Mathys, Post-fire mechanical properties of marine polymer composites, Composite Structures, vol. 47, pp.643-653, (1999).

DOI: 10.1016/s0263-8223(00)00043-x

[7] A. Mouritz, Z. Mathys, Post-fire mechanical properties of glass-reinforced polyester composites, Composites Science and Technology, vol. 64, pp.475-490, (2001).

DOI: 10.1016/s0266-3538(00)00204-9

[8] A. Mouritz, Post-fire flexural properties of fibre-reinforced polyester, epoxy and phenolic composites, Journal of Materials Science, vol. 37, pp.1377-1386, (2002).

[9] W. An, L. Jiang, J. Sun, K. Liew, Correlation analysis of sample thickness, heat flux, and cone calorimetry test data of polystyrene foam, Journal of Thermal and Analysis and Calorimetry, vol. 119, pp.229-238, (2015).

DOI: 10.1007/s10973-014-4165-9

[10] X. Chen, S. Lu, C. Li, J. Zhang, K. Liew, Experimental study on ignition and combustion characteristics of typical oils, Fire and Materials, vol. 38, pp.409-417, (2014).

DOI: 10.1002/fam.2191

[11] M. B. Avila, The effect of resin type and glass content on the fire engineering properties of typical FRP composites, M.S. thesis, Department of Fire Protection Engineering, Worcester polytechnic institute, (2007).

[12] G. Ramsay, V. Dowling, B. McKechnie, J. Leonard, Methods For Assessing The Fire Performance Of Phenolic Resins And Composites, Fire Safety Science, vol. 2, pp.355-366, (1995).

[13] Reaction-to-fire tests-heat release, smoke production and mass loss rate-part 1: heat release rate (cone calorimeter method), ISO Standard 5660-1, 2nd ed., Geneva: International Organization for Standardization, (2002).

DOI: 10.3403/30255889

[14] Reaction to Fire-Mass Loss Measurement, ISO Standard 17554, Geneva: International Organization for Standardization, (1998).

[15] J. Luche, T. Rogaume, F. Richard, E. Guillaume, Characterization of thermal properties and analysis of combustion behavior of PMMA in a cone calorimeter, Fire Safety Journal, vol. 46, pp.451-461, (2011).

DOI: 10.1016/j.firesaf.2011.07.005

[16] L. Shi, M. Chew, Fire behaviors of polymers under autoignition conditions in a cone calorimeter, Fire Safety Journal, vol. 61, pp.243-253, (2013).

DOI: 10.1016/j.firesaf.2013.09.021

[17] J. Luche, E. Mathis, T. Rogaume, F. Richard, E. Guillaume, High-density polyethylene thermal degradation and gaseous compound evolution in a cone calorimeter, Fire Safety Journal, vol. 54, pp.24-35, (2012).

DOI: 10.1016/j.firesaf.2012.08.002

[18] M. Delichatsios, B. Paroz, A. Bhargava, Flammability properties for charring materials, " Fire Safety Journal, vol. 38, pp.219-228, (2003).

DOI: 10.1016/s0379-7112(02)00080-2

[19] R. Chen, S. Lu, B. Zhang, C. Li, S. Lo, Correlation of rate of gas temperature rise with mass loss rate in a ceiling vented compartment, Chinese Science Bulletin, vol. 59, pp.4559-4567, (2014).

DOI: 10.1007/s11434-014-0479-z

[20] J. Quintiere, A theoretical basis for flammability properties, Fire and Materials, vol. 30, pp.175-214, (2006).

DOI: 10.1002/fam.905

[21] V. Babrauskas, R. D. Peacock, Heat release rate: the single most important variable in fire hazard, Fire Safety Journal, vol. 18, pp.255-272, (1992).

DOI: 10.1016/0379-7112(92)90019-9
