Numerical/Experimental Research on Welded Joints in Aluminium Truss Girders

Abstract:

Welded joints in a 30 meter span aluminium truss girder were investigated numerically and experimentally. Since aluminium design rules for welded K-and N-joints in CHS truss girders were lacking the joints were checked using steel design rules. Calculations showed that the N-joints were governing for chord and brace sizes. Further numerical analysis on the N-joints using ANSYS 11.0 was carried out. Full scale experimental research was successfully carried out for validation of the numerical calculations. It is concluded that steel design rules predict the failure behavior and failure mode of the considered aluminium N-joints well. However, steel design rules overestimate the failure load by 8% for the truss configurations investigated.

You might also be interested in these eBooks

Aluminium Constructions: Sustainability, Durability and Structural Advantages

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 710)

Pages:

295-300

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.710.295

Citation:

Cite this paper

Online since:

September 2016

Authors:

Dianne van Hove*, Frans Soetens

Keywords:

Aluminium Truss Girders, Welded Joints

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] A. Taher, Onderzoeksproject Aluminium, Master Project, Eindhoven University of Technology, Faculty of Architecture, Building and Planning, Unit Structural Design, Report O-2008. 25 (in Dutch), June (2008).

Google Scholar

[2] B.W.E.M. van Hove and F. Soetens, Experimental research on pinned connections in aluminium truss girders, HERON, Vol. 55 (2010) No. 3, Delft, (2010).

Google Scholar

[3] NEN 6772, TGB 1990 Verbindingen (Dutch regulations and rules for calculation of predominantly statically loaded connections in steel structures).

Google Scholar

[4] EN 1993-1-1, Eurocode 3, Design of steel structures – Part 1. 1: General rules for buildings.

Google Scholar

[5] NEN 6710, Dutch basic regulations and basic rules for calculation of predominantly statically loaded aluminium structures).

Google Scholar

[6] EN 1999-1-1, Eurocode 9, Design of aluminium structures – Part 1. 1: General rules for buildings.

Google Scholar

[7] A. Taher, Aluminium buisconstructies, Master of Science Report (in Dutch), Eindhoven University of Technology, Department of Architecture Building and Planning, Unit Structural Design, July (2010).

Google Scholar
