Lattice Modelling of the Onset of Concrete-Ice Abrasion

Abstract:

The last decades the concrete-ice abrasion process has been well known as a concrete surface degradation mechanism due to ice sliding. The topic is especially relevant for concrete gravity based structures in the Arctic offshore. The article presents a numerical model in which the onset of wear in the concrete-ice abrasion process is simulated. The simulations are performed on meso-scale, which means that concrete is modelled as a three-phase material in which paste, aggregates and the interface transition zone are distinguished. Lattice modelling is adopted for the numerical modeling. Hertzian contact theory which predicts excessive tensile stresses on the concrete surface due to sliding of ice asperities is used as an analytical basis for the numerical model. It was concluded that such model is able to capture both surface and subsurface cracking in the concrete.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 351-358
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.351
• Online since: September 2016
• Authors: Nathalie Ramos, Guzel Shamsutdinova*, Max A.N. Hendriks, Stefan Jacobsen
• Keywords: Abrasion, Concrete, Ice, Lattice Modelling

References

[1] S. Jacobsen, G. W. Scherer and E. M. Schulson, Concrete-Ice Abrasion Mechanics, Cement and Concrete Research, 73 (2015) 79–95.

DOI: 10.1016/j.cemconres.2015.01.001

[2] Y. Itoh, A. Yoshida, M. Tsuchiya, K. Katoh, K. Sasaki and H. Saeki, An experimental study on abrasion of concrete due to sea ice, Presented at the 20th Annual Offshore Technology Conference in Houston, Texas, May 2–5 (1988) 61–68.

DOI: 10.4043/5687-ms

[3] A.T. Bekker, T.E. Uvarova, E.E. Pomnikov, A.E. Farafonov, I.G. Prytkov and R.S. Tyutrin, Experimental Study of Concrete Resistance to Ice Abrasion. Proceedings of the 21-th Int. Offshore and Polar Engineering Conference, Maui, Hawaii, USA, June 19-24 (2011).

[4] A. M. Nawwar and V. M. Malhotra, Development of a Test Method to Determine the Resistance of Concrete to Ice Abrasion and/or Impact, American Concrete Institute SP 109 (1988) 401-426.

DOI: 10.14359/3585

[5] G. Shamsutdinova, P. B. Rike, M. A. Hendriks and S. Jacobsen, Concrete Ice Abrasion Rig and Wear Measurements, International Conference on Port and Ocean Engineering under Arctic Conditions, Trondheim, 23 (2015).

[6] E. Schlangen and E.J. Garboczi, Fracture Simulations of Concrete Using Lattice Models: Computational Aspects, Engineering Fracture Mechanics 57 (2-3) (1997) 319-332.

DOI: 10.1016/s0013-7944(97)00010-6

[7] G. Lilliu and J. G. van Mier, On The Relative Use of Micro-Mechanical Lattice Analysis of 3-Phase Particle Composites, Engineering Fracture Mechanics 74 (7) (2007) 1174-1189.

DOI: 10.1016/j.engfracmech.2006.12.018

[8] P. V. Hoobbs, Ice Physics, Oxford University Press (2010) 668.

[9] R. Taylor, R. Frederking and I. Jordan, The Nature of High Pressure Zones in Compressive Ice Failure, The 19th International Symposium on Ice, Vancouver, (2008) 1001-1010.

[10] B. Basu and M. Kalin, Tribology of Ceramics and Composites. A material Science Perspective, New Jersey, (2011).

[11] K. Jonson, Contact Mechanics, London, (1985).
