Recycled Concrete Mixes for Slip-Form Paving of Roads and Airports

Abstract:

Slip-form paving is gaining consensus in road and airport construction due to high production rates and automation of the process. Concrete slabs are extruded by pulling the forms continuously through and surrounding the plastic concrete mass. The technology uses low-slump cement concrete mixes so that the fresh mass is able to hold its shape once the slip-form paver has passed; besides low-slump, several other parameters should be considered for a proper slip-form concrete mix, especially at the fresh state. To date, recycling is being commonly adopted in concrete mixes to address sustainability in construction of transport infrastructures. Recycled Concrete Aggregates (RCA) are used to reduce the consumption of virgin materials although their increased porosity leads to higher absorption and generally lower mechanical performance. The present study aimed at evaluating the compatibility of 100% recycled concrete mixes with slip-form paving; recycled concrete was tested to evaluate the fresh-state properties as well as the hardened strength. Results showed that slip-form effective and high-resistance mixes could be prepared by using high content of RCA.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 730-736
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.730
• Online since: September 2016
• Authors: Maurizio Crispino, Emanuele Toraldo, Filippo Giustozzi*, Edoardo Mariani
• Keywords: Aggregates, Concrete, Recycling, Slip-Form Paving

References

[1] EN 12350-2, Testing fresh concrete: Slump-test. (2009).

[2] EN 206-1, Concrete. Specification, performance, production and conformity. (2013).

[3] AFCESA/CES, Engineering Technical Letter (ETL) 97-5: Proportioning Concrete Mixtures with Graded Aggregates for Rigid Airfield Pavements, (1997).

[4] M. Magnoni, E. Toraldo, F. Giustozzi, and M. Crispino, Recycling practices for airport pavement construction: Valorisation of on-site materials; Construction and Building Materials, Volume 112, Pages 59–68, (2016).

DOI: 10.1016/j.conbuildmat.2016.02.142

[5] EN 1097-2, Tests for mechanical and physical properties of aggregates. Methods for the determination of resistance to fragmentation. (2010).

[6] LEED v4 for Building Design and Construction, US Green Building Council, (2016).

[7] EN 12350-5, Testing fresh concrete. Flow table test. (2009).

[8] EN 12350-4, Testing fresh concrete. Degree of compactability. (2009).

[9] EN 12350-6, Testing fresh concrete. Density. (2009).

[10] EN 12350-7, Testing fresh concrete. Air content. Pressure methods. (2009).

[11] EN 12390-3, Testing hardened concrete. Compressive strength of test specimens. (2009).

[12] EN 12390-6, Testing hardened concrete. Tensile splitting strength of test specimens. (2009).

DOI: 10.3403/30200045

[13] EN 12390-5, Testing hardened concrete. Flexural strength of test specimens. (2009).

[14] EN 12390-13, Testing hardened concrete. Determination of secant modulus of elasticity in compression. (2013).

DOI: 10.3403/30397532

[15] EN 933-1, Tests for geometrical properties of aggregates - Part 1: Determination of particle size distribution - Sieving method. (2012).

DOI: 10.3403/01236185u

[16] EN 933-4, Tests for geometrical properties of aggregates - Part 4: Determination of particle shape - Shape index. (2008).

DOI: 10.3403/01879218u

[17] EN 933-3, Tests for geometrical properties of aggregates - Part 4: Determination of particle shape - Flakiness index. (2013).

DOI: 10.3403/01114528u

[18] EN 1097-6, Tests for mechanical and physical properties of aggregates - Part 6: Determination of particle density and water absorption. (2008).

[19] EN 197-1, Cement. Composition, specifications and conformity criteria for common cements. (2011).

[20] NCHRP Synthesis 435, Recycled Materials and Byproducts in Highway Applications, Volume 6: Reclaimed Asphalt Pavement, Recycled Concrete Aggregate, and Construction Demolition Waste, Febbraio (2013).

DOI: 10.17226/22547

[21] G. Gonzalez, H. Moo-Young, Transportation Applications of Recycled Concrete Aggregate, FHWA State of the Practice National Review. Washington D.C.: Federal Highway Administration. (2004).

[22] T. Spry, Evaluation of Recycled Concrete Aggregate Produced from Demolished Runway Panels as a Substitute for Coarse Aggregate in New Portland Cement Pavements. MS Thesis. Department of Civil and Environmental Engineering, Washington State University, Pullman, Washington. (2013).

[23] P. Amorim, J. de Brito, and L. Evangelista, L. Concrete Made with Coarse Concrete Aggregate: Influence of Curing on Durability. ACI Materials Journal. (2012).

DOI: 10.14359/51683706
