High Corrosion Resistant GFRP-UFC Composite Beams for Short Span Pedestrian Bridges

Abstract:

This paper describes the development of high corrosion resistant glass fiber reinforced polymer (GFRP) and ultra-high strength fiber reinforced concrete (UFC) composite beams for construction of short span pedestrian bridges. The main advantage of these composite beams is, they can be used in corrosive environments at a low maintenance cost. The UFC slab is consisted of precast segments and those segments were connected to the GFRP I-beam top flange using FRP bolts and epoxy adhesive. Large-scale four point bending tests were carried out in order to select the suitable FRP bolt parameters for the composite beam. The experiment results revealed that the FRP bolts can be used instead of the steel bolts, as the shear connectors in the GFRP and UFC composite beams. The composite beams having non-headed FRP bolts exhibited better flexural capacity compared to the beams with FRP headed-bolts. Fiber model analysis was carried out on the composite beams and there was a good agreement between the analysis and experiment results. The experiment results were used to construct a short span pedestrian bridge in Miyagi prefecture, Japan. The static loading tests were carried out on that bridge for three loading types. The short span bridge showed acceptable performance in the loading tests.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 759-766
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.759
• Online since: September 2016
• Authors: Sanjaya Kumara Wijayawardane Isuru*, Hiroshi Mutsuyoshi
• Keywords: Corrosion Resistance, Glass Fiber Reinforced Polymer, High Durability, Short Span Bridge, Ultra-High Strength Fiber Reinforced Concrete

References

[1] I. Nishizaki, N. Takeda, Y. Ishizuka and T. Shimomura, A case study of life cycle cost based on a real FRP bridge, Proceedings of Third International Conference on FRP Composites in Civil Engineering (CICE), Florida, USA, 2006, pp.99-102.

[2] N.D. Hai, H. Mutsuyoshi, S. Asamoto and T. Matsui, Structural behavior of hybrid FRP composite I-beam, Construction and Building Materials, 24 (6) 956-969. (2010).

DOI: 10.1016/j.conbuildmat.2009.11.022

[3] I.S.K. Wijayawardane, H. Mutsuyoshi and S.V.T.J. Perera, Innovative composite girders using FRP I-beams and precast UFC slab segments, Proceedings of 7th International Conference on FRP Composites in Civil Engineering (CICE), Vancouver, Canada, (2014).

[4] N. Watanabe, H. Musha and K. Yoshinaga, Design and performance tests for bridge using ultra high strength fiber reinforced concrete, 23rd US–Japan Bridge Engineering Workshop, Tsukuba, Japan, (2007).

[5] Y. Uchida, Y. Tanaka, M. Katagiri and J. Niwa, Outline of JSCE Recommendations for design and construction of ultra high strength fiber reinforced concrete structures (Draft), Concrete Journal, 43 (3) 3-8. (2005).

DOI: 10.3151/coj1975.43.3_3

[6] A. Manalo and T. Aravinthan, Behaviour of glued fibre composite sandwich structure in flexure: Experiment and Fibre Model Analysis, Materials & Design, 39 458-468. (2012).

DOI: 10.1016/j.matdes.2012.02.052

[7] JSCE, Recommendations for Design and construction of ultra high strength fiber reinforced concrete structures (Vol. 9), JSCE Guidelines for Concrete, Japan Society of Civil Engineers Tokyo, Japan, 2004, 1-106.

DOI: 10.2208/jscejmcs.77.3_119

[8] Japan Road Association, Technical standard for solid crossing facilities, Japan Road Association, Japan, 1979. (in Japanese).

[9] JSCE, Guidelines for design and construction of FRP footbridges, Japan Society of Civil Engineers, 2011. (in Japanese).
