Process Effects in Short Cycle Stretch Forming of Tinplate Can Bodies

Abstract:

Short Cycle Stretch Forming (SCS) is an innovative stretch forming technology developed at the Institute for Metal Forming Technology (IFU) at the University of Stuttgart. The SCS technology combines plane pre-stretching of blank and subsequent deep drawing operations within the same stroke of press ram. The sheet metal thickness is reduced while denting resistance and yield stress increases due to hardening effects.Current research work focuses on applying SCS-technology to rotational-symmetrical bodies. A process simulation for SCS-Cupping process was performed for food cans. Based on these results a tool was manufactured and commissioned. The results showed that the thickness of cup bottoms of two-piece drawn and ironed (D&I) steel cans can be reduced. Therefore, it is possible to save material costs in serial production based on a reduced blank diameter.In this paper the different effects leading to the thinning of steel can bottom and failure types, such as, wrinkling and cracking are observed in a number of experimental series. Based on these results, the tool geometry was optimized and an advanced tool was manufactured. The results of this paper show that SCS-Cupping offers promising potential to save material, as well as outlining the main effects for this technology.

• Periodical: Key Engineering Materials (Volume 716)
• Pages: 494-501
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.716.494
• Online since: October 2016
• Authors: Matthias Schneider*, Mathias Liewald
• Keywords: Sheet Metal, Stretch Forming, Tinplate, Tool Geometry

References

[1] M. Liewald, D. Vlahovic, Device for even Stretch-Forming of Workpieces, Patent No DE 10 2006 047 484 A1(2006).

[2] A. Papaioanu, M. Liewald, Further Development of the SCS Stretch-Forming Technology with Assistance of Forming Simulation, 13th International ESAFORM Conference on Material Forming (2010), p.155 – 158.

DOI: 10.1007/s12289-010-0730-3

[3] A. Papaioanu, M. Liewald, SCS – Innovativer Herstellungsprozess für Außenhautteile, ZWF - Zeitschrift für wirtschaftlichen Fabrikbetrieb, 106 (2011) p.644 – 646.

DOI: 10.3139/104.110617

[4] Dejan Vlahovic, Neue technologische Ansätze zum kombinierten Recken und Tiefziehen von Außenhautbeplankungen aus Feinblech, dissertation, University of Stuttgart, (2009).

[5] C. Bath, Streckziehen von Karosserieteilen., Werkstatt und Betrieb, 1965, Nr. 3.

[6] W. Hommel, Verfahren und Vorrichtung zum Ziehen von Blechen, Patentnummer DE102010048406 A1 (2012).

[7] A. Büchler, Weißblech für Verpackungen: Herstellung Verwendung und Recycling, (Moderne Industrie, Landsberg/Lech, 1999), ISBN: 3-478-93208-4.

[8] M. Schneider, M. Liewald, Approach for implementation of Short Cycle Stretch Forming (SCS) to cupping Processes, Key Engineering Materials Vols. 611-612 (2014), pp.1096-1101.

DOI: 10.4028/www.scientific.net/kem.611-612.1096

[9] M. Schneider, M. Liewald, Effects of Process Variation in Short Cycle Stretch Forming in Beverage Can Production, in: F. Chinesta, E. Cueto (Eds. ), 19th International ESAFORM Conference on Material Forming (2016).

DOI: 10.1063/1.4963466

[10] E. Siebel, H. Beisswänger, Tiefziehen, Hanser Verlag, (1955).
