Ferrofluid Plug Actuation for Micro Pumping Systems

Abstract:

Ferrofluids are colloidal mixtures which consist of nanosized magnetic particles suspended in a base fluid. The typical magnetic particles could be maghemite, magnetite or cobalt ferrite etc. To keep a ferrofluid suspension in a stable state is possible by an electrical double layer or by adding surfactant. They have many applications on electrical, mechanical and optical systems. Recently, the ability of being manipulated by an external magnetic field made them considerable for microfluidic systems such as micro operations, pumping and mixing. Among them, micro scaled pumping systems have appeared as a critical research area due to its notable potential to be applied on many biological and electronic systems. Moreover, the development of lab on a chip and the micro total analysis systems for biological issues has revealed the necessity of liquid transport for micro quantities. Micropumps with ferrofluid plug actuation mechanisms are considered to have the ability to fulfill this requirement. Therefore, driving the working fluids with ferrofluid plugs in a micro-sized tube or channel has attracted researchers’ interest. In this study, ferrofluid plug actuated micro pumping systems have been reviewed from the available literature based on their design and their maximum generated flow rate.

• Periodical: Key Engineering Materials (Volume 750)
• Pages: 168-172
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.750.168
• Online since: August 2017
• Authors: Serkan Doganay*, Alpaslan Turgut, Levent Cetin
• Keywords: Ferrofluid, Ferrofluid Plug, Magnetic Field, Magnetic Particle, Micro Pump, Microfluidics

References

[1] D.J. Laser, J.G. Santiago, A review of micropumps. Journal of Micromechanics and Microengineering 14 (2004), 35-64.

[2] B.D. Iverson, S.V. Garimella, Recent advances in microscale pumping technologies: a review and evaluation. Microfluidics and Nanofluidics 5 (2008), 145-174.

DOI: 10.1007/s10404-008-0266-8

[3] S.C. Chen, C.H. Cheng, Y.C. Lin, Analysis and experiment of a novel actuating design with a shear mode PZT actuator for microfluidic application. Sensors and Actuators a-Physical 135 (2007), 1-9.

DOI: 10.1016/j.sna.2006.10.016

[4] H.T. Chang, C.Y. Lee, C.Y. Wen, Design and modeling of a MEMS-based valveless pump driven by an electromagnetic force. DTIP 2006: Symposium on Design, Test, Integration and Packaging of MEMS/MOEMS 2006 (2006), 255-259.

DOI: 10.1109/dtip.2014.7056626

[5] C. Yamahata, M. Chastellain, V.K. Parashar, A. Petri, H. Hofmann, M.A.M. Gijs, Plastic micropump with ferrofluidic actuation. Journal of Microelectromechanical Systems 14 (2005), 96-102.

DOI: 10.1109/jmems.2004.839007

[6] K.F. Lei, W.C. Law, Y.K. Suen, W.J. Li, Y. Yam, H.P. Ho, S.K. Kong, A vortex pump-based optically-transparent microfluidic platform for biotech and medical applications. Proceedings of the Institution of Mechanical Engineers Part H-Journal of Engineering in Medicine 221 (2007).

DOI: 10.1243/09544119jeim189

[7] V. Singhal, S.V. Garimella, Induction electrohydrodynamics micropump for high heat flux cooling. Sensors and Actuators a-Physical 134 (2007), 650-659.

DOI: 10.1016/j.sna.2006.05.007

[8] S. Aggarwal, B.E. Paul, A. DasGupta, D. Chatterjee, Experimental characterization of piezoelectrically actuated micromachined silicon valveless micropump. Microfluidics and Nanofluidics 21, (2017).

DOI: 10.1007/s10404-016-1837-8

[9] D.H. Liu, G.H. Liao, Study of valveless micropump based on MEMS technology. Advanced Research on Mechanical Engineering, Industry and Manufacturing Engineering 63 (2011), 800-803.

[10] E. Sayar, B. Farouk, Bulk acoustic wave piezoelectric micropumps with stationary flow rectifiers: a three-dimensional structural/fluid dynamic investigation. Microfluidics and Nanofluidics 18 (2015), 433-445.

DOI: 10.1007/s10404-014-1441-8

[11] Y.H. Xu, W.P. Yan, T. Cao, L. Guo, Ieee, Study on the valveless micropumps with saw-tooth microchannels, 11th IEEE International Conference on Control and Automation, 2014, 1251-1254.

DOI: 10.1109/icca.2014.6871102

[12] R.J. Yang, H.H. Hou, Y.N. Wang, L.M. Fu, Micro-magnetofluidics in microfluidic systems: A review. Sensors and Actuators B-Chemical 224 (2016), 1-15.

DOI: 10.1016/j.snb.2015.10.053

[13] M.A.M. Gijs, F. Lacharme, U. Lehmann, Microfluidic Applications of Magnetic Particles for Biological Analysis and Catalysis. Chemical Reviews 110 (2010), 1518-1563.

DOI: 10.1021/cr9001929

[14] A. Hatch, A.E. Kamholz, G. Holman, P. Yager, K.F. Bohringer, A ferrofluidic magnetic micropump. Journal of Microelectromechanical Systems 10 (2001), 215-221.

DOI: 10.1109/84.925748

[15] J.J. Ahn, J.G. Oh, B. Choi, A novel type of a microfluidic system using ferrofluids for an application of mu-TAS. Microsystem Technologies-Micro-and Nanosystems-Information Storage and Processing Systems 10 (2004), 622-627.

DOI: 10.1007/s00542-003-0340-9

[16] C. Yamahata, M.A.M. Gijs, Ieee, Plastic micropumps using ferrofluid and magnetic membrane actuation, 17th IEEE International Conference on Micro Electro Mechanical Systems, Maastricht, NETHERLANDS, 2004, 458-461.

DOI: 10.1109/mems.2004.1290621

[17] H. Hartshorne, C.J. Backhouse, W.E. Lee, Ferrofluid-based microchip pump and valve. Sensors and Actuators B-Chemical 99 (2004), 592-600.

DOI: 10.1016/j.snb.2004.01.016

[18] H. Kumamaru, S. Okamoto, K. Arimoto, K. Itoh, Y. Shimogonya, Experimental Study on Micropump using Reciprocating Motion of Magnetic Ball Covered with Magnetic Fluid. 12th International Conference on Magnetic Fluids Icmf12 9 (2010), 238-242.

DOI: 10.1016/j.phpro.2010.11.053

[19] L. -M. Fu, W. -C. Fang, T. -F. Hong, C. -Y. Lee, A Magnetic Micropump Based on Ferrofluidic Actuation. 4 (2014).
