Quality Control of the Concrete of the Supporting Structure of Bridge Reg. No. 333-003 over the Elbe in Přelouč

Abstract:

This paper is introducing results of diagnostic survey of bridge reg. No. 333-003 over the Elbe in Přelouč [1], which included an evaluation of the previous reconstruction carried out in the 1990s [2, 3] and the quality control of the concrete used in the construction after more than 90 years of operation. Visual inspection, comparison of depth of concrete carbonation and thickness of top layer of reinforcement concrete and concrete compression strength are presented in this paper. This paper come into existence with cooperation with the state-funded organization Road Administration and Maintenance of the Pardubice Region.

• Periodical: Key Engineering Materials (Volume 760)
• Pages: 278-285
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.760.278
• Online since: January 2018
• Authors: Stanislav Rehacek*, David Citek, Jiří Kolisko
• Keywords: Bridge, Carbonation, Concrete, Strength

References

[1] Technical report no.: 1600 J 215 - Construction and technical research supporting the bridge structure no. 333-003, Bridge across Labe river, Klokner Institute, CTU in Prague, 01/(2017).

[2] TP 72: Diagnostic survey of bridges PK, Pontex spol s r. o., December (2008).

[3] The bridge inspection, Bridge no. 333-003, Bridge across Labe river in Prelouc, made by Ing. Micka – PONTEX s. r. o, October (2012).

[4] Scanned drawings (plan view, cross sections and details), the project of reconstruction of the bridge across the Labe river in Prelouc, a project to supply competition in 1993, submitted by the client representative.

[5] TKP 31: Repair of concrete structures, Ministry of Transport, Department of Infrastructure Approved byMD-OI, č. j. 318/08-910-IPK/1, Prague, May (2009).

[6] TP SSBK III: Technical conditions for the rehabilitation of concrete structures.

[7] ČSN 73 1373: Hardness testing methods of concrete.

[8] ČSN ISO 13822: Principles of design of structures - Assessment of existing structures, (January 2015), including the newly released CSN 73 00 38.

[9] ČSN EN 12504-2: Testing concrete in structures. Part 2: Non-destructive testing - Determination of rebound number (March 2002).

DOI: 10.3403/30397523

[10] ČSN EN 13791: Assessment of concrete compressive strength in structures and precast concrete parts.

[11] ČSN EN 12504-1: Testing concrete in structures - Part 1: Cored specimens - withdrawal, examining and testing in compression.

DOI: 10.3403/02050563u

[12] TKP 18: Specifications for road construction, Ministry of Transport, Department of roads Approved MD-OPK ref 474/05-120-RS/1, Prague, August (2005).

[13] ČSN 73 2011: Nedestruktivní zkoušení betonových konstrukcí.
