Simulation of Translational Data Acquisition Scheme of X-Ray Computed Tomography for Application in NDT

Abstract:

The invention of computed tomography some few decades ago, coupled with its applications in the field of non-destructive testing for industrial objects inspection has revolutionized the way inspections were formerly done. Despite the conventional data acquisition scheme which is integrated with a rotational stage in between the source and the detector works perfectly for small and lighter objects, hence, it seems impossible to investigate complicated, bulky objects with interconnected unbalanced composites. Moreover, it will be very expensive to harnessed technologies into the rotational stage which can be incorporated into this conventional technique with an optimum degree of accuracy. Therefore, this paper will consider the translational data acquisition scheme which is proven mathematically as an alternative method to the conventional technique [1]. This translational scheme takes into account the variations and the magnification of both the source x-ray and the detector around the object and then proceeded by scans from different focal distances. Python packages with necessary plugins were used in implementing the reconstructive algorithm generated in simulating and modelling a suitable image of inspected object.

• Periodical: Key Engineering Materials (Volume 769)
• Pages: 256-261
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.769.256
• Online since: April 2018
• Authors: Bright Kwame Afornu*, Odii Christopher Joseph, Ali Ozdiev, Dmitriy Sednev
• Keywords: Non-Destructive Testing (NDT), Reconstruction Algorithms, Simulation, Translational Data Acquisition Scheme, X-Ray Tomography

References

[1] Fuchs T., Schon T., Hanke R., A Translation-based Data Acquisition Scheme for Industrial Computed Tomography, ECNDT, (2010).

[2] Cantatore A., Müller P., Introduction to computed tomography,, DTU, Department of Mechanical Engineering, Denmark, (2011).

[3] Avinash K., Malcolm S., Principles of Computerized Tomographic Imaging,, [Electronic copy 1999] IEEE Press, ISBN 0-87942-198-3.

[4] Ozdiev, A., X-ray tomography simulation based on direct radon transform, Volume 743 KEM, 2017, Pages 445-448.

DOI: 10.4028/www.scientific.net/kem.743.445

[5] URL: https://radiopaedia.org/articles/filtered-back-projection-1.

[6] Dudgeon and Mersereau (1984), Multidimensional digital signal processing,Prentice-Hall.

[7] A.C. Kak and M. Slaney, Principles of Computerized Tomographic Imaging,, IEEE Press, 1988, Pages 49 – 63.
