Simulation Analysis of Clamping Force in Welding Process of Aluminum Alloy Flankwall of Urban Rail Vehicle

Abstract:

In the welding process, the welding strain and deformation of the city rail aluminum alloy flankwall are inevitable as a result of local heating, and carrying capacity of the structure will be affected by the welding stress and deformation. In the mean time, it puts forward some requirements for the clamp process, the clamping force can reduce the deformation of the workpiece. But a great change of force will produce in the clamp position during the process of welding, this force changes are easy to cause brittle fracture and fatigue damage of the clamp. In this paper, it gives simulation analysis to workpiece by using ANSYS analysis software and Gauss heat source model. Finally, the conclusion is sum up compared with the actual data.
