Molecular Dynamic Investigation on the Dissolution Behaviour of Carbamazepine Form III in Ethanol Solution

Abstract:

Carbamazepine (CBZ) is well known to have low solubility, hence an understanding of crystal behaviour is vital to improve the solubility of the drugs, hence for the oral bioavailability. The objectives of this work are to assess the morphology prediction of the most stable form of CBZ, which form (III) and to access the dissolution behaviour of the crystal. Material Studio 4.0 was used to predict the morphology of CBZ form (III) based on attachment energy calculations in vacuum condition by using the combination of MNDO charges from MOPAC with PCFF potential function. Later, predicted morphology was used for dissolution prediction in ethanol solvent using dynamic simulation with CVFF potential function. From the result, the morphology prediction of CBZ form (III) produced hexagonal – like shape with seven dominated facets; (011), (11-1), (100), (10-2), (020), (110) and (11-2) with the most morphological important is (011) face with 45.23% area while the fastest growing facet is (11-2) which only 0.91% area contributed to the whole crystal. The lattice energy calculated was -21.62 kcal/mol with only 1.36% error compared to the experimental value; -21.33 kcal/mol. The dissolution prediction result shows that small facet area with the amine and carbonyl groups exposed at the surface will dissolve readily than the other facets. This result explains that the small facet area with protruding functional groups that can form the hydrogen bond to ethanol molecules will be the most favourable facet to dissolve.

• Periodical: Key Engineering Materials (Volume 797)
• Pages: 149-157
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.797.149
• Online since: March 2019
• Authors: Siti Nurul'ain Yusop*, Nornizar Anuar, Md Azmi Nik Salwani, Nurul Hidayah Abu Bakar
• Keywords: Carbamazepine, Mean Square Displacement, Molecular Dynamic Simulation, Morphology

References

[1] H. C. S. Chan, J. Kendrick, M. A. Neumann, F. J. J. Leusen, and R. Road, Electronic Supplementary Information, p.1–11, (2013).

[2] K. J. R. Robert, B. Hammond, K. Pencheva, A Structural-Kinetic Approach to Model Face-Specific Solution/ Crystal Surface Energy Associated with the Crystallization of Acetyl Salicylic Acid from Supersaturated Aqueous/Ethanol Solution, Cryst. Growth & Design, 6 (2006), p.11.

DOI: 10.1021/cg0505618

[3] N. Anuar, W. Ramli, W. Daud, K. J. Roberts, S. K. Kamarudin, and S. M. Tasirin, Morphology and Associated Surface Chemistry of L-Isoleucine Crystals Modeled under the Influence of L-leucine Additive Molecules. Crsytal Growth & Design, 12 (2012). 2195-2203.

DOI: 10.1021/cg200266e

[4] Y. Yang, D. Han, S. Du, S. Wu, and J. Gong, Crystal morphology optimization of thiamine hydrochloride in solvent system : Experimental and molecular dynamics simulation studies. 481 (2018). 48–55.

DOI: 10.1016/j.jcrysgro.2017.10.022

[5] L Song, L Chen, J Wang, F Chen, G Lan. Prediction of crystal morphology of 3, 4-Dinitro-1H-pyrazole (DNP) in different solvents. Journal of Molecular Graphics and Modelling 75 (2017) 62 – 70.

DOI: 10.1016/j.jmgm.2017.03.013

[6] G Clydesdale, KJ Roberts, GB Telfer, DJW Grant. Modelling the crystal morphology of α-lactose monohydrate. Journal of Pharmaceutical Sciences 86 (1997) 135 – 141.

DOI: 10.1021/js950496w

[7] AL Rohl. Computer prediction of crystal morphology. Current Opinion in Solid State and Materials Science 7 (2003) 21 – 26.

DOI: 10.1016/s1359-0286(03)00019-6

[8] W Shi, Y Chu, M Xia, W Lei, F Wang. Crystal morphology prediction of 1,3,3-trinitroazetidine in ethanol solvent by molecular dynamics simulation. Journal of Molecular Graphics and Modelling 64 (2016) 94 – 100.

DOI: 10.1016/j.jmgm.2016.01.004

[9] X. Duan, C. Wei, Y. Liu, and C. Pei, A molecular dynamics simulation of solvent effects on the crystal morphology of HMX, vol. 174, p.175–180, (2010).

DOI: 10.1016/j.jhazmat.2009.09.033

[10] W. Shi, M. Xia, W. Lei, and F. Wang, Solvent effect on the crystal morphology of 2,6-diamino-3,5-dinitropyridine-1-oxide: A molecular dynamics simulation study. J. Mol. Graph. Model. 50 (2014) p.71–77.

DOI: 10.1016/j.jmgm.2014.03.005

[11] R. B. Teklebrhan, L. Ge, S. Bhattacharjee, Z. Xu, J. Sjo, and C. Tg, Probing Structure − Nanoaggregation Relations of Polyaromatic Surfactants : A Molecular Dynamics Simulation and Dynamic Light Scattering Study. (2012).

DOI: 10.1021/jp3010184

[12] A Liljeblad. Evaluation of Crystalline Solid Properties: Experimental and Theoretical Comparison of Polymoprhs, Solvates, aand Co-crystals. Master's Thesis. Chalmers University of Technology, Gothenburg. (2015).

[13] P. Bukovec, A. Meden, M. Smrkolj, and F. Vre, Influence of Crystal Habit on the Dissolution of Simvastatin Single Crystals. p.958–966, (2015).

DOI: 10.17344/acsi.2015.1849

[14] C. Wang. Effects of solvent and supersaturation on crystal experimental and computer simulation study, CrystEngComm, (2016).

[15] J Zeng, W Aimin, G Xuedong, C Jingwen, C Song, X Feng. Molecular dynamics simulation of diffusion of vitamin c in water solution. Chinese Journal of Chemistry. 30 (2012) 115 – 120.

[16] R Gholizadeh, Y Wang, Y-X Yu. Molecular dynamics simulations of stability at the early stages of silica materials preparation. Journal of Molecular Structure 1138 (2017) 198 – 207.

DOI: 10.1016/j.molstruc.2017.03.021
