Development of Evaluation Method for Damage of Oxidation CoNiCrAlY Coating

Abstract:

The bond coat plays an important role in the failure of the thermal barrier coating (TBC) system used for gas turbines ^{[1, 2]}. In this research, the CoNiCrAlY coated Ni-base superalloy specimens were used for developing evaluation method for interfacial damage in the coat. Samples were exposed at 1000°C and 1100°C for up to 1000 hours. The morphology and residual stress in the thermally grown oxide (TGO) layer on the CoNiCrAlY coating were characterized by microscopic observation and luminescence spectroscope, respectively. The microstructure and damage o\n both the coating surfaces and the cross sections were observed by optical microscope and scanning electron microscope. According to the results, the low pressure plasma sprayed CoNiCrAlY coating (LPPS) showed the thinnest TGO layer and lowest residual stress.Residual stress decreased with an increase in exposure time, depending on the morphology of TGO layer. The effects of thermal spraying methods on the oxidation of yttrium in TGO layer and BC layer and its influence on interfacial damage were discussed.

• Periodical: Key Engineering Materials (Volume 804)
• Pages: 47-51
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.804.47
• Online since: May 2019
• Authors: Mo Chen, Kodai Yoshikawa, Zhen Qiang Song, Shijie Zhu*
• Keywords: CoNiCrAlY Coating, Plasma Spray, Residual Stress, TGO, Thermal Exposure

References

[1] R. Vaßen, et al. Overview on advanced thermal barrier coatings, Surface & Coatings Technology, 2010 (205), pp.938-942.

DOI: 10.1016/j.surfcoat.2010.08.151

[2] M. Shibata, et al. Comparison of microstructure and oxidation behavior of CoNiCrAlY bond coatings prepared by different thermal spray processes, Materials Transactions, 2006 (47), pp.638-1642.

DOI: 10.2320/matertrans.47.1638

[3] W.R. Chen, et al. TGO growth behavior in TBCs with APS and HVOF bond coats, Surface & Coatings Technology, 2008 (202), pp.2677-2683.

DOI: 10.1016/j.surfcoat.2007.09.042

[4] J.A. Nychka, D.R. Clarke. Damage quantification in TBCs by photo-stimulated luminescence spectroscopy. Surface & Coatings Technology. 2001 (146-147), pp.110-116.

DOI: 10.1016/s0257-8972(01)01455-4

[5] K. Yoshikawa. Microscopic analysis and residual stress evaluation of high temperature oxide on CoNiCrAlY coating, Master's thesis, Fukuoka Institute of Technology, (2017).

[6] J. Jedliski. Comments on the effect of yttrium on the early stages of oxidation of alumina formers, Oxidation of Metals, 1993 (39), pp.55-60.

DOI: 10.1007/bf00666609
