Investigation of the Hammer Forging Process of Large-Sized Turbine Blades of Stainless Steel

Abstract:

Investigations of the rheological properties and the formation of the structure of stainless steel were performed. A computer model of the process of hammer forging of the turbine blades made of stainless steel 1.3 m long in the package Deform-3D was developed , with the help of which the necessary coefficients and parameters are determined to ensure maximum convergence of the calculated and experimental process data. The obtained data were used to create a mathematical model for stamping a large-sized turbine blade made of stainless steel with a length of 2.1 m. Mathematical modeling of the processes of stamping and distorting of a large-sized blade in the software package Deform-3D has been performed. The influence of process parameters on the stress-strain state (SSS), forming, temperature field in the forging at various stages of stamping. Determined temperature and deformation modes of stamping, the need for additional heating and optimal forgings geometry by stamping.

• Periodical: Key Engineering Materials (Volume 822)
• Pages: 150-158
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.822.150
• Online since: September 2019
• Authors: Maksim Olegovich Smirnov*, Tatiana Chizhik, Alexander M. Zolotov
• Keywords: Mathematical Simulation, Plastic Deformation, Stamping, Stamping Hammer, Steam-Air Hammer, Turbine Blade
