Experimental Verification of the Stiffness of a Semi-Rigid Timber Connection

Abstract:

Modern fasteners offer new options for the design of timber load-bearing structures. In the design, the traditional hinged connections are increasingly being replaced with semi-rigid connections. Nevertheless, there is no feedback from the actual structures with this kind of connection regarding the accuracy of static calculations. The authors therefore decided to test one connection and compare the results with those obtained from calculation models. The paper presents the experimental verification of the frame connection in which the semi-rigid action was achieved by combining the aluminium Sherpa connector and total thread Rothoblaas screws. The timber samples were provided by Latti Extra.

• Periodical: Key Engineering Materials (Volume 832)
• Pages: 63-72
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.832.63
• Online since: February 2020
• Authors: Jaroslav Sandanus, Kristián Sógel*, Tomáš Klas, Michal Botló
• Keywords: Experimental Verification, Semi-Rigid Connection, Timber Engineering, Timber Structures

References

[1] V. Duchoň, T. Klas, O. Katona, J. Brodniansky, Ľ. Balcierák, J. Sandanus, K. Sógel: Experimental Tests of Timber Connections with Glued-in Rods in Bending, in Wood Research, Vol. 61, No. 4, 2016, pages 565-572.

DOI: 10.1201/9781315393827-27

[2] D. Mikolášek, K. Vavrušová, O. Sucharda, P. Pařenica, R. Fojtík, J. Hurta, Numerické modely lepených kotev doplněné experimentálním měřením, Vysoká škola báňská, Technická univerzita Ostrava, Fakulta stavební, (2015).

[3] STN EN 1995-1-1 + A1. Navrhovanie drevených konštrukcií. Časť 1-1: Všeobecne – Všeobecné pravidlá a pravidlá pre budovy. SÚTN, Bratislava, (2008).

[4] Screws for Wood (catalogue by Rothoblaas). Available in december 2016 on: http://www.rothoblaas.com/en/it/catalogues/fastening-systems.html.

[5] Sherpa Manual (catalogue by Sherpa). Available in december 2016 on: http://en.sherpa-connector.com/dl/Sherpa_Handbuch_en/blaetterkatalog/index.html.

DOI: 10.7717/peerj.13893/table-2

[6] Šmak, M.,Barnat, J., Straka, B., Kotásková, P., Havířová, Z.: Dowelled joints in timber structures experiment-design-realization, in Wood Research, Vol. 61, No. 4, 2016, pages 651-662.

[7] Lokaj, A., Klajmonová, K.: Round timber bolted joints exposed to static and dynamic loading, in Wood Research, Vol. 59, No. 3, 2014, pages 439-448.

DOI: 10.4028/www.scientific.net/amr.1020.199

[8] STN EN 380. Drevené konštrukcie. Skúšobné metódy. Všeobecné zásady skúšania statickým zaťažením. SÚTN, Bratislava, (1998).
