Study on Deep Hole Drilling Process and Cutting Performance

Abstract:

In deep hole machining, drilling parameters for twist drills have an important impact on tool life and economic efficiency. In order to explore the influence of drilling parameters on twist drills, this paper established a drilling model for twist drill 45 steel, orthogonal experiments were designed. AdvantEdge FEM finite element software was used to simulate the drilling force, torque and drilling temperature. The drilling force, torque and drilling temperature were analyzed by using the finite element simulation value as the orthogonal experimental value. In order to ensure that the simulation results have certain reference value, the drilling experiment was carried out in order to ensure the simulation results have reference value. Finally, the optimal combination of drilling parameters was obtained.

• Periodical: Key Engineering Materials (Volume 866)
• Pages: 42-53
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.866.42
• Online since: October 2020
• Authors: F.Q. You, R. Zhang, Yong Guo Wang*
• Keywords: Deep Hole Twist Drill, Drilling Force, Finite Element Simulation, Torque
