Study of the Influence of SBS and APDDR on the Low-Temperature Properties of Road Bitumen

Abstract:

A comparative assessment of the effect of two modifiers on the low-temperature properties of BND 90/130 bitumen was investigated using Asphalt Binder Cracking Device (ABCD test) and Dynamic Shear Rheometer (DSR 4-mm test). These modifiers are styrene-butadiene-styrene block copolymer (SBS) and active powder of discretely devulcanized rubber (APDDR) - powder elastomeric modifier obtained by high-temperature shear grinding of waste tire crumb rubber. ABCD results of RTFO-aged samples showed clear and gradual decrease of the ABCD cracking temperature (improvement) for all BC as the modifier concentration increases. It is noteworthy that the Bitumen Composites (modified bitumens) were cracking at higher strain and fracture stress values compared to neat bitumen. Results of DSR-4 mm test showed a decrease in the complex shear modulus (G*), storage modulus (G¢) and loss modulus (G²) BC compared to the neat bitumen. It is shown that bituminous composites have no maximum on the Cole-Cole diagram (dynamic vitrification) at T = -28°C which is observed in the neat bitumen.

• Periodical: Key Engineering Materials (Volume 899)
• Pages: 50-57
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.899.50
• Online since: September 2021
• Authors: V.N. Gorbatova, Tatiana V. Dudareva*, Irina A. Krasotkina, Vadim G. Nikol'skii, Yulia A. Naumova, V.D. Polonik, D.Yu. Egorov
• Keywords: Active Powder of Discretely Devulcanized Rubber, Dynamic (Mechanic) Glass Transition, Low-Temperature Cracking Resistance, Road Bitumen, Styrene-Butadiene-Styrene Block Copolymer

References

[1] D.A. Anderson, D.W. Christoensen, H.U. Bahia, et al., SHRP-F-369 Binder Characterization and Evaluation. Vol. 3. Physical Characterization, Washington, DC, (1994).

[2] S.I. Dubina, V.G. Kandrashin, The Quality of Russian Highways, Transport of the Russian Federation. 2 (2006) 49-50.

[3] EN 12593:2015 Bitumen and Bituminous Binders. Determination of the Fraass Breaking Point.

DOI: 10.3403/30138272

[4] P. Radziszewski, M. Sarnowski, J. Król, P.et al., Low Temperature Requirements for Bitumen in Central East European Road Construction, The Baltic Journal of Road and Bridge Engineering. 14 (2) (2019) 249–270.

DOI: 10.7250/bjrbe.2019-14.442

[5] J. D'Angelo et al, Revision of the Superpave High Temperature Binder Specification: The Multiple Stress Creep Recovery Test, Journal of the Association of Asphalt Paving Technologists. 76 (2007) 123-162.

[6] E.A. Romasyuk, Dorozhnye Asfal'topolimerbetony s Kompleksno-Modificirovannoj Strukturoj Povyshennoj Ustalostnoj Dolgovechnosti. Diss. kand. tekhn. nauk [Road Asphalt-polymer Concrete with a Complex-modified Structure of Increased Fatigue Life. Ph.D. Tesis]. Makeevka, (2015).

[7] V. A. Zolotarev, Dolgovechnost' dorozhnyh asfal'tobetonov [Durability of Road Asphalt Concrete], V. N. Karazin Kharkiv National University, (1977).

[8] Polymer Modified Bitumen, Woodhead Publishing, Cambridge, UK, (2011).

[9] M. Porto, P. Caputo, V. Loise, et al., Bitumen and Bitumen Modification: A Review on Latest Advances, Appl. Sci. 9 (4) (2019) 742.

DOI: 10.3390/app9040742

[10] H. L. Von Quintus, J. Mallela, M. Buncher, Quantification of Effect of Polymer-Modified Asphalt on Flexible Pavement Performance, Journal of Transportation Research Board. 2001 (2007) 141-154.

DOI: 10.3141/2001-16

[11] D. Lesueur, The Colloidal Structure of Bitumen: Consequences on the Rheology and on the Mechanisms of Bitumen Modification, Advances in Colloid and Interface Science. 145 (2009) 42-82.

DOI: 10.1016/j.cis.2008.08.011

[12] AASHTO T 313 Determining the Flexural Creep Stiffness of Asphalt Binder Using the Bending Beam Rheometer (BBR). (2019).

DOI: 10.1520/d6648-08r16

[13] AASHTO TP 92-14 Determining the Cracking Temperature of Asphalt Binder Using the Asphalt Binder Cracking Device (ABCD). (2018).

[14] M. Farrar, Technical White Paper. Determining the Low-Temperature Rheological Properties of Asphalt Binder Using a Dynamic Shear Rheometer (DSR). Fundamental Properties of Asphalts and Modified Asphalts III Product, FP 08 March, (2015).

DOI: 10.1520/d7175-05

[15] E. Jellema, E. Scholten, S. De Vries, et al. Comparing Cold Performance Results Using Fracture Toughness Test, Asphalt Binder Cracking Device, Fraass Breaking Point and Bending Beam Rheometer, 5th Eurasphalt & Eurobitume Congress, 13-15th June 2012, Istanbul.

[16] Sorokin, A.V., et al., Patent RF 2612637 (2017).

[17] A.A. Berlin, V.G. Nikolskii, I.A. Krasotkina, et al., Problems of Effectiveness Evaluation of Modifiers Introduced into Asphalt Concrete Mixtures According to «Russian Dry Process», Vse Materialy. Entsiklopedicheskii Spravochnick, 2 (2021) 2-9.

[18] AASHTO T 240-13 Standard Method of Test for Effect of Heat and Air on a Moving Film of Asphalt (Rolling Thin-Film Oven Test). (2017).

DOI: 10.1520/d2872

[19] N.I. Chekunaev, A.M. Kaplan, On Increase of Strength and Fatigue Life of Asphalt Composites by Introducing Ultra-Small Particles of Elastomers, Procedia Materials Science, 3, 2014, p.698–705.

DOI: 10.1016/j.mspro.2014.06.115

[20] V. Gordeeva, Yu. A. Naumova, V. G. Nikol'skii, et al., Analysis of Flow Curves of Modified Bitumen Composites, Polymer Science. Series D. 13 (2) (2020) 151–156.

DOI: 10.1134/s1995421220020094

[21] AASHTO R 28-12 Accelerated Aging of Asphalt Binder Using a Pressure Aging Vessel (PAV). (2016).

[22] V.N. Gorbatova, I.V. Gordeeva, T.V. Dudareva, et al., Rheological Properties of Bitumen with Powder Rubber Modifier Obtained by High-Temperature Shear Grinding. In: Vatin N. (eds.) Proceedings of EECE 2020. Lecture Notes in Civil Engineering. 150 (2021) 475-485.

DOI: 10.1007/978-3-030-72404-7_46
