FE Crash Modeling of Aluminum-FRP Hybrid Components Manufactured by a Hybrid Forming Process

Abstract:

Through the patented process of hybrid forming [1], it is possible to produce a bonded metal-plastic-hybrid component in one process step with the help of an edge-sealed pressing tool. Such a component exhibits an enormous energy absorption potential. To use this complete potential, a reliable FE-Modelling is necessary, that can exactly replicate the complex material layup consisting of an isotropic metal, a very thin bonding layer, and an anisotropic glass mat reinforced thermoplastic (GMT) for crash load case. A methodology is proposed to numerically predict the behavior of the metal GMT aluminum components. And finally, the experimental results of Hybrid components are validated for three-point bending and axial crash load cases.

• Periodical: Key Engineering Materials (Volume 926)
• Pages: 2050-2059
• DOI: https://doi.org/10.4028/p-w0hue6
• Online since: July 2022
• Authors: Saarvesh Jayakumar, Lorenz Stolz*, Sharath Anand, Amir Hajdarevic, Xiang Fan Fang
• Keywords: Anisotropic, Crash Modeling, Hybrid Forming
