Effect of High Temperature and Humidity on Bond Strength of Al/Resin Adhesive Joints

Abstract:

The adhesive strength and degradation behavior of the Al/resin interface was investigated under high temperature and high humidity conditions. The adhesive strength of the joint without aging was approximately 14 MPa. The value is the same as the Cu/resin joint. With progress of aging at 85°C in 85%R. H., the strength decreased rapidly in the early aging stage and decreased gradually by further aging. The strength of the Al/resin joint was inferior to that of the Cu/resin joint after aging. The fracture mainly occurred in the interface of the joint. The result of Fourier transform infrared spectroscopy analysis for the fracture surface showed that water absorption in the Al/resin joint occurs by aging and causes the degradation of the strength.

• Periodical: Key Engineering Materials (Volume 967)
• Pages: 63-68
• DOI: https://doi.org/10.4028/p-XZXg5O
• Online since: December 2023
• Authors: Itsuki Watanabe*, Tatsuya Kobayashi, Ikuo Shohji
• Keywords: Aluminium, Bond Strength, Epoxy Resin, Thermal Humidity Test, Water Absorption

References

[1] L. Lorenz, Power semiconductor devices - driving technology for power conversion systems, Fuji Electric Journal 95 (2022) 175-177.

[2] A. Matallana, E. Ibarra, I. López, J. Andreu, J.I. Garate, X. Jordà, J. Rebollo, Power module electronics in HEV/EV applications: New trends in wide-band gap semiconductor technologies and design aspects, Renewable and Sustainable Energy Reviews 113 (2019) 109264.

DOI: 10.1016/j.rser.2019.109264

[3] F. Roccaforte, P. Fiorenza, G. Greco, R.L. Nigro, F. Giannazzo, F. Iucolano, M. Saggio, Emerging trends in wide band gap semiconductors (SiC and GaN) technology for power devices, Microelectronic Engineering 187-188 (2018) 66-77.

DOI: 10.1016/j.mee.2017.11.021

[4] K. S. Tan, K. Y. Cheong, Mechanical properties of sintered Ag-Cu die-attach nanopaste for application on SiC device, Mater. Des. 64 (2014) 66-176.

DOI: 10.1016/j.matdes.2014.07.033

[5] T. P. Chow, High-voltage SiC and GaN power devices, Microelectronic Engineering, 83 (2006) 112-122.

DOI: 10.1016/j.mee.2005.10.057

[6] Y. Yamada, T. Iseki, Bonding of mold resin to copper substrate through an amorphous interlayer film, Journal of Smart Processing 8 (2019) 162-168.

DOI: 10.7791/jspmee.8.162

[7] Y. Tang, L. Ge, H. Gu, Y. Bai, Y. Luo, C. Lid, X. Liu, Degradation in electrothermal characteristics of 4H-SiC junction barrier Schottky diodes under high temperature power cycling stress, Microelectronics Reliability 102 (2019) 113451.

DOI: 10.1016/j.microrel.2019.113451

[8] Y. Tonozuka, T. Kobayashi, I. Shohji, H. Hokazono, K. Takahashi, T. Ezure, Evaluation of deterioration life of interface of copper and epoxy resin under high temperature and high humidity conditions, Journal of Smart Processing 7 (2018) 128-134.

DOI: 10.7791/jspmee.7.128

[9] X. Zhao, H. Mitsugi, I. Shohji, T. Kobayashi, Investigation of mechanical properties of high Tg epoxy resin material, Journal of Smart Processing 10 (2021) 365-371.

DOI: 10.7791/jspmee.10.365

[10] R. Suzuki, I. Shohji, T. Kobayashi, Y. Tonozuka, Effect of temperature and humidity on degradation behavior of Cu/epoxy interface under high temperature and high humidity aging, Materials Science Forum, 1016 (2021) 1436-1442.

DOI: 10.4028/www.scientific.net/msf.1016.1436

[11] H. Mitsugi, R. Suzuki, I. Shohji, T. Kobayashi, Deterioration behavior of epoxy resin for electronics packaging and its adhesive joint with Ni by water absorption, Journal of Smart Processing 10 (2021) 359-364.

DOI: 10.7791/jspmee.10.359
