Marble-Looking Fired Clay Tiles Produced by Utilizing Local Clay and Glass Cullet

Abstract:

This research is aim at developing marble-looking fired clay tile by utilizing waste glass cullet (CGC) mixed up with local plastic clay, sediment soil, and laterite clay. Boric oxide is also used as sintering aid. The experimental formulation is divided into 3 groups (A, B, and C) with 27 formulas. Test samples are moulded at 100 bar by Uni-axial pressing in dimension 50 x 100 x 7 mm and fried at temperature 850 °C. The initial results show that all formulas can develop marble texture and achieve Thai Industrial Standard TIS 2508-2555. Reducing firing temperature to 800 °C is the further investigation. However, formulas consisting 90% glass cullet are not selected, due to difficulty of molding workpieces. The final results of firing 800^o C show that formula A6 containing 15% Plastic clay, 85% glass cullet, 2% boric oxide has the highest bending strength and lowest water absorption (<1%). Its properties are similar to formula C6 containing 15% laterite soil 85% glass cullet, 2% boric oxide. They can pass Thai Industrial Standard TIS 2508-2555 Floor Tiles BI_b. Analyzing microstructure the fired specimens of these formulas by Scanning Electron Microscope has found glassy phases and dense matrix structures. Furthermore, Nepheline, Quartz, Cristobalite, Wollastonite, Devitrite, and Albite are identified by X-Ray Diffractometer. It can be summarized that marble texture surface fired clay tile can be developed by utilizing waste glass and low cost local materials.

• Periodical: Key Engineering Materials (Volume 987)
• Pages: 75-82
• DOI: https://doi.org/10.4028/p-VWJ6tX
• Online since: September 2024
• Authors: Witsanu Loetchantharangkun, Chonlathit Pitipoomsuksan*, Ubolrat Wangrakdiskul
• Keywords: Boric Oxide, Glass Cullet, Low Sintering Temperature, Marble-Looking Clay Tile

References

[1] "Report the situation of solid waste disposal locations in Thailand, 2022," Departmet of Pollution Control, Ministry of Natural Resources and Environment, Bangkok, 2022.

[2] "Composition of Solid Wastes in 2021," Pollution Control Department, Bangkok, Thailand, 2022.

[3] "Annual Report 2022 Metropolitan Waterworks Authority," Metropolitan Waterworks Authority, Thailand, 2022.

[4] U. Wangrakdiskul, "Sustainable unglazed and low sintering temperature wall tiles by reutilizing sediment soil from the water supply treatment process," Songklanakarin Journal of Science and Technology, vol. 42, no. 5, pp.1117-1124, 2020.

DOI: 10.4028/www.scientific.net/msf.917.303

[5] P. Chantruthai, T. Areepong, S. Issaron and S. Jaritngam, "Investigating Lateritic Soil Properties and Impacts from Quarrying Activity on Communities in Southern Thailand: A Case Study," ENGINEERING JOURNAL, vol. 21, no. 1, pp.265-278, 2017.

DOI: 10.4186/ej.2017.21.1.265

[6] "Mining of Marble and its Environmental Impact," Indian Natural Stone Exporter, Manufacturer, Supplier & Factory, [Online]. Available: https://www.regattaexports.com/mining-of- marble-and-its-environmental-impact/. [Accessed 30 11 2023].

[7] I. Demir, "Reuse of waste glass in building brick production," Waste Management & Research, vol. 27, p.572–577, 2009.

DOI: 10.1177/0734242x08096528

[8] V. Loryuenyong, T. Panyachai , K. Kaewsimork and C. Siritai, "Effects of recycled glass substitution on the physical and mechanical properties of clay bricks," Waste Management, vol. 29, p.2717–2721, 2009.

DOI: 10.1016/j.wasman.2009.05.015

[9] N. Phonphuak, S. Kanyakam and P. Chindaprasirt, "Utilization of waste glass to enhance physical-mechanical properties of fired clay brick," Journal of Cleaner Production, vol. 112, pp.3057-3062, 2016.

DOI: 10.1016/j.jclepro.2015.10.084

[10] S.M.S. Kazmi, S. Abbas, M.L. Nehdi, M. A. Saleem and M. J. Munir, "Feasibility of Using Waste Glass Sludge in Production of Ecofriendly Clay Bricks," Journal of Material in Civil Engineering, vol. 29, no. 8, p.04017056: 1-12, 2017.

DOI: 10.1061/(asce)mt.1943-5533.0001928

[11] U. Wangrakdiskul and W. Loetchantharangkun, "Utilizing Green Glass Cullet, Local Ball Clay and White Clay for Producing Light Greenish Brown Color Wall Tile," European Journal of Engineering Science and Technology, vol. 2, no. 3, pp.23-30, , 2019.

DOI: 10.33422/ejest.2019.08.14

[12] S.R. Teixeira, G.T. A. Santos, A.E. Souza, P. Alessio, S.A. Souza and N.R. Souza, "The effect of incorporation of a Brazilian water treatment plant sludge on the properties of ceramic materials," Applied Clay Science, vol. 53, p.561–565, 2011.

DOI: 10.1016/j.clay.2011.05.004

[13] C. Martínez-García, D. Eliche-Quesada, L. Pérez-Villarejo, F. J. Iglesias-Godino and F. A. Corpas-Iglesias, "Sludge valorization from wastewater treatment plant to its application on the ceramic industry," Journal of Environmental Management , vol. 95, pp. S343-S348, 2012.

DOI: 10.1016/j.jenvman.2011.06.016

[14] Y. Pei Ling, R.-H. Tham, S.-M. Lim, M. Fahim and C.-H. Ooi, "Evaluation and reutilization of water sludge from fresh water processing plant as a green clay substituent," Applied Clay Science, vol. 143, p.300–306, 2017.

DOI: 10.1016/j.clay.2017.04.007

[15] U. Wangrakdiskul, K. Benjaratthapong and M. Jongtrakulsir, "Crushed Limestone Dust Valorization for Eco Friendly non Fired Wall Tiles," MATEC Web of Conferences6, vol. 64, pp.1-5, 2016.

DOI: 10.1051/matecconf/20166407002

[16] U. Wangrakdiskul, T. Poommong and P. Tubtimkeaw, "Enhancement Bending Strength of Non Fired Wall Tiles by Recovering Sand-Wastes By-Products from Kaolin Beneficiation Process," Key Engineering Materials, vol. 877, pp.123-130, 2021.

DOI: 10.4028/www.scientific.net/kem.877.123

[17] E. Uwe, A. R. Boccaccini , S. G. Cook and C. R. Cheeseman, "Effect of borate addition on the sintered properties of pulverised fuel ash," Ceramics International 33, vol. 33, p.993–999, 2007.

DOI: 10.1016/j.ceramint.2006.02.013

[18] S.U. Bayca, "Effects of the addition of ulexite to the sintering behavior of a ceramic body," Journal of Ceramic Processing Research, vol. 10, no. 2, p.162~166, 2009.

[19] U. Wangrakdiskul and D. Pirunrat , "New texture with black grey color of fired clay wall tiles produced from rice husk ash, brown glass cullet, and local plastic clay," IOP Conf. Series: Materials Science and Engineering, vol. 652, pp.1-8, 2019.

DOI: 10.1088/1757-899x/652/1/012051
