Globular Crystals in the Center of Roll Cast Aluminum Alloy Strips

Abstract:

This study investigated the crystallization position and formation mechanism of globular crystals at the center area in the thickness direction of aluminum alloy strips cast by a high-speed twin roll caster. Twin roll casters for single strips and clad strips were used, as well as twin roll casters equipped with a cooling slope. The globular crystals were formed from dividing arms of dendrites of the solidified layer facing the center area at the roll gap. The arms of isolated dendrite also divided. No globular crystals were formed at the interfaces of clad strips with different solidification temperatures because of the temperature gradient at the interface which inhibited division of the dendrite arms. It was demonstrated that globular crystals at the center area of the thickness direction were formed by dendrite-arm-dividing at the roll gap by the strip casting clad strip. Experiments by semisolid-strip casting with the cooling slope showed that globular crystals in the molten metal existed in the solidification layers.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1007)

Pages:

34-40

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.1007.34

Citation:

Cite this paper

Online since:

August 2020

Authors:

Toshio Haga*, Maho Tsuchida, Hirotaka Sakata, Hisaki Watari, Shinichi Nishida

Keywords:

Globular Crystal, Semisolid, Temperature Gradient, Twin Roll Caster

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] A. Unal, Continuous casting of aluminum, U.S. Patent No. 6,672,368. Washington, DC: U.S. Patent and Trademark Office, (2004).

Google Scholar

[2] T. Haga, K. Takahashi, H. Watari, Semisolid strip casting using a vertical type twin roll caste, Mater. Sci. Forum, 426(1) (2003) 477-482.

DOI: 10.4028/www.scientific.net/msf.426-432.477

Google Scholar

[3] T. Haga, K. Takahashi, M. Ikawa, H. Watari, A vertical type twin roll caster for aluminum alloy strips, J. Mater. Proce. Technol. 140(1-3) (2003) 610-615.

DOI: 10.1016/s0924-0136(03)00835-5

Google Scholar

[4] T. Haga, K. Takahashi, M. Ikawa, H. Watari, Twin roll casting of aluminum alloy strips, J. Mater. Proce. Technol. 153-154 (2004) 42-47.

DOI: 10.1016/j.jmatprotec.2004.04.018

Google Scholar

[5] R. Nakamura, K. Takahashi, M. Ikawa, Aluminum Alloy Strips Casting Using an Unequal Diameter Twin Roll Caster, Mater. Sci. Forum, 449-452 (2004) 145-148.

DOI: 10.4028/www.scientific.net/msf.449-452.145

Google Scholar

[6] T. Haga, H. Inui, H. Watari, S. Kumai, Casting of Al–Si hypereutectic aluminum alloy strip using an unequal diameter twin roll caster, J. Mater. Proce. Technol. 191(1-3) (2007) 238-241.

DOI: 10.1016/j.jmatprotec.2007.03.012

Google Scholar

[7] T. Haga, H. Sakaguchi, H. Inui, H. Watari, S. Kumai, Aluminum alloy semisolid strip casting using an unequal diameter twin roll caster, J. Ach. Mater. Manuf. Eng. 14(1-2) (2006) 157-162.

DOI: 10.1002/9783527607969.ch17

Google Scholar

[8] T. Haga, Semisolid strip casting using a twin roll caster equipped with a cooling slope, J. Mater. Proce. Technol. 130 (2002) 558-561.

DOI: 10.1016/s0924-0136(02)00765-3

Google Scholar

[9] T. Haga, R. Nakamura, S. Kumai, H. Watari, Clad strip casting by a twin roll caster, Arch. Mater. Sci. Eng. 37(2) (2009) 117-124.

DOI: 10.1007/978-1-84996-432-6_8

Google Scholar

[10] T. Haga, K. Ikeda, T. Nakano, Roll Casting of 400 mm Width Al-40%Sn-1%Cu Clad Strip, Mater. Sci. Forum, 904 (2017) 3-8.

DOI: 10.4028/www.scientific.net/msf.904.3

Google Scholar

[11] T. Haga, P. Kapranos, Billetless simple thixoforming process, J. Mater. Proce. Technol. 130 (2002) 581-586.

DOI: 10.1016/s0924-0136(02)00817-8

Google Scholar
