Effect of Spray Distance on the Microstructure and High Temperature Oxidation Resistance of Plasma Spray-Physical Vapor Deposition 7YSZ Thermal Barrier Coating

Abstract:

In order to study the effect of spray distance on the structure and high temperature oxidation resistance of feather-columnar thermal barrier coatings, the feather-columnar ZrO₂-7wt. % Y₂O₃ (7YSZ) thermal barrier coatings were prepared at spray distances of 650 mm, 950 mm, 1100 mm, 1250 mm, and 1400 mm by plasma spray-physical vapor deposition (PS-PVD) technology. The surface roughness, micro morphology, and porosity of the sprayed 7YSZ coating were analyzed by 3D surface profiler, SEM, XRD, etc., and the impedance spectrum characteristics of the 7YSZ coating were characterized by electrochemical alternating current (AC) impedance technology. In addition, the high temperature oxidation resistance test of 7YSZ coating under different spray distances was carried out at a temperature of 1000 °C to study the influence of spray distance on the high temperature oxidation resistance of 7YSZ coating. The research results show that the surface roughness and porosity of feather-columnar 7YSZ coating increased sequentially with the increase of spray distance. At the same time, The YSZ grain boundary resistance value increased exponentially as the porosity of the coating increases. Where the spray distance was in the range of 650 mm and 1250 mm, the high temperature oxidation rate constant of the coating increased with the spray distance. However, the spray distance was greater than 1250 mm, and the spray distance had no significant effect on the high temperature oxidation resistance of the coating.

• Periodical: Materials Science Forum (Volume 1035)
• Pages: 511-520
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1035.511
• Online since: June 2021
• Authors: Wen Long Chen*, Min Liu, Xiao Ling Xiao, Xin Zhang
• Keywords: High Temperature Oxidation Resistance, Microstructure, Plasma Spray-Physical Vapor Deposition, Spray Distance, Thermal Barrier Coating

References

[1] R. Vaßen, M.O. Jarligo, T. Steinke, et al. Overview on advanced thermal barrier coatings, Surface and Coatings Technology, 205(2010) 938-942.

DOI: 10.1016/j.surfcoat.2010.08.151

[2] D.R. Clarke, M. Oechsner, N.P. Padture, Thermal-barrier coatings for more efficient gas-turbine engines, MRS bulletin, 37(2012) 891-898.

DOI: 10.1557/mrs.2012.232

[3] P. K. Wright, A.G. Evans, Mechanisms governing the performance of thermal barrier coatings, Current Opinion in Solid State and Materials Science, 4 (1999) 255-265.

DOI: 10.1016/s1359-0286(99)00024-8

[4] I. Gurrappa, A.S. Rao, Thermal Barrier Coatings for Enhanced Effificiency of Gas Turbine Engines, Surface and Coatings Technology, 201(2006) 3016-3029.

DOI: 10.1016/j.surfcoat.2006.06.026

[5] M.F. Smith, A.C. Hall, J.D. Fleetwood, et al. Very low pressure plasma spray-a review of an emerging technology in the thermal spray community, Coatings, 2(2011)117-132.

DOI: 10.3390/coatings1020117

[6] M. Goral, S. Kotowski, A. Nowotnik, et al. PS-PVD deposition of thermal barrier coatings[J]. Surface and Coatings Technology, 237 (2013) 51-55.

DOI: 10.1016/j.surfcoat.2013.09.028

[7] A. Hospach, R. Vaben, D. Stover. Characteristics of ceramic coatings made by thin film low pressure plasma spraying (LPPS-TF). Journal of Thermal Spray Technology, 21(2012)435-440.

DOI: 10.1007/s11666-012-9748-z

[8] B. Harder. PS-PVD processing varies coating architecture with processing parameters[J]. Advanced Materials and Processes, 169(2011) 49-51.

[9] K.V. Niessen, M. Gindrat, A. Refle. Vapor phase deposition using plasma spray-PVD [J]. Journal Thermal Spray Technology, 19(2010) 502-509.

DOI: 10.1007/s11666-009-9428-9

[10] G. Maure, M.O. Jarligo, S. Rezanka, et al. Novel opportunities for thermal spray by PS-PVD, Surface and Coatings Technology, 268(2015) 52-57.

DOI: 10.1016/j.surfcoat.2014.06.002

[11] L.H. Gao, H.B. Guo, L.L. Wei, et al. Microstructure and mechanical properties of yttria stabilized zirconia coatings prepared by plasma spray physical vapor deposition, Ceramics International, 41(2015) 830-8311.

DOI: 10.1016/j.ceramint.2015.02.141

[12] D.R. Mumm, A.G. Evans. On the role of imperfections in the failure of a thermal barrier coating made by electron beam deposition, Acta materialia, 48(2000) 1815-1827.

DOI: 10.1016/s1359-6454(99)00473-5

[13] X.F. Bi, H.B. Xu, S.K. Gong. Investigation of the failure mechanism of thermal barrier coatings prepared by electron beam physical vapor deposition. Surface and Coatings Technology, 130(2000) 122-127.

DOI: 10.1016/s0257-8972(00)00693-9

[14] O. Trunova, T.Beck, R. Herzog, et al. Damage mechanisms and lifetime behavior of plasma sprayed thermal barrier coating systems for gas turbines-Part I: experiments, Surface and Coatings Technology, 202(2008) 5027-5032.

DOI: 10.1016/j.surfcoat.2008.05.006

[15] M.S. Li. High temperature corrosion of metal, Beijing, 2001, pp.59-86.
