Sprayability Analysis of Pristine and Enhanced PEDOT:PSS Inks via Electrohydrodynamic Spray Deposition

Abstract:

Poly (3,4-ethylene dioxythiophene) polystyrene sulfonate (PEDOT:PSS) is a conductive polymer and versatile material to fabricate numerous organic electronic devices. PEDOT:PSS inks were studied and analyzed for their sprayability via Electrohydrodynamic (EHD) printing. Commercially obtained pristine PEDOT:PSS ink could not produce any decent cone-jet mode due to its high surface tension and viscosity. Two different surfactants – acetone and ethanol were then dispersed into PEDOT:PSS at different concentrations to enhance the sprayability of the PEDOT:PSS ink. Both modified PEDOT:PSS inks could produce a cone-jet mode of spraying, which is essential for EHD printing. The flow rates were tested between 10 - 20 μl/hr. These limits were established to prevent the splashing effect at a higher flow rate (>20μl/hr) and inks disintegrating at a lower flow rate 5μl/hr. PEDOT:PSS:Acetone and PEDOT:PSS:Ethanol with 50:50 and 75:25 ratios, respectively, produced the best performance in their respective categories.

• Periodical: Materials Science Forum (Volume 1076)
• Pages: 65-72
• DOI: https://doi.org/10.4028/p-e7k1q6
• Online since: December 2022
• Authors: Zulfikre Esa, Malik Muhammad Nauman*, Iqbal Asif, Juliana Hj Zaini
• Keywords: Electrohydrodynamic, Electrospraying, PEDOT:PSS, Printed Electronics, Thin Films

References

[1] A. Jilani, Advance Deposition Techniques for Thin Film and Coating,, M. S. Abdel-Wahab, Ed. Rijeka: IntechOpen, 2017, p. Ch. 8.

[2] G. D. Martin and I. M. Hutchings, Fundamentals of Inkjet Technology,, in Inkjet Technology for Digital Fabrication, Chichester, UK: John Wiley & Sons, Ltd, 2014, p.21–44.

DOI: 10.1002/9781118452943.ch2

[3] D. Gao and J. G. Zhou, Designs and applications of electrohydrodynamic 3D printing,, Int. J. Bioprinting, vol. 5, no. 1, p.1–11, 2019,.

[4] K. Barton, S. Mishra, K. A. Shorter, A. Alleyne, P. Ferreira, and J. Rogers, A desktop electrohydrodynamic jet printing system,, Mechatronics, vol. 20, no. 5, p.611–616, 2010,.

DOI: 10.1016/j.mechatronics.2010.05.004

[5] N. M. Muhammad, N. Duraisamy, H. W. Dang, J. Jo, and K.-H. Choi,Solution processed Al doped ZnO film fabrication through electrohydrodynamic atomization,, Thin Solid Films. vol. 520, pp.6398-6403, 2012,.

DOI: 10.1016/j.tsf.2012.06.050

[6] K.-H. Choi, A. Ali, A. Rahman, N. M. Muhammad, K. Rahman, A. Khan, S. Khan, D.-S. Kim, Electrode configuration effects on the electrification and voltage variation in an electrostatic inkjet printing head: J. Micromech. Microeng. Vol. 20, 075033, 2010,.

DOI: 10.1088/0960-1317/20/7/075033

[7] A. Jaworek and A. Krupa, Classification of the modes of EHD spraying,, J. Aerosol Sci., vol. 30, no. 7, p.873–893, 1999,.

DOI: 10.1016/s0021-8502(98)00787-3

[8] N. Duraisamy, N. M. Muhammad, A. Ali, J. Jo, and K. H. Choi, Characterization of poly(3,4-ethylene dioxythiophene):poly(styrenesulfonate) thin film deposited through electrohydrodynamic atomization technique,, Mater. Lett., vol. 83, p.80–83, 2012,.

DOI: 10.1016/j.matlet.2012.05.127

[9] U. Farooq, I. Khan, S. Ahmad, M. Abas, M. A. Zaib Khan, and K. Rahman, Fabrication of PEDOT: PSS conductive patterns on photo paper substrate through electrohydrodynamic jet printing process,, Int. J. Light. Mater. Manuf., vol. 2, no. 4, p.318–329, 2019,.

DOI: 10.1016/j.ijlmm.2019.06.002

[10] J. Dai et al., Printed gas sensors,, Chem. Soc. Rev., vol. 49, no. 6, p.1756–1789, 2020,.

[11] S. E. Park, J. Y. Hwang, K. Kim, B. Jung, W. Kim, and J. Hwang, Spray deposition of electrohydrodynamically atomized polymer mixture for active layer fabrication in organic photovoltaics,, Sol. Energy Mater. Sol. Cells, vol. 95, no. 1, p.352–356, 2011,.

DOI: 10.1016/j.solmat.2010.04.057

[12] J. Kim, N. Duraisamy, T. M. Lee, I. Kim, and K. H. Choi, Hybrid electrohydrodynamic atomization of nanostructured silver top contact for inverted organic solar cells,, Sol. Energy Mater. Sol. Cells, vol. 130, p.156–162, 2014,.

DOI: 10.1016/j.solmat.2014.06.034

[13] K. Kim et al., High-resolution electrohydrodynamic jet printing of small-molecule organic light-emitting diodes,, Nanoscale, vol. 7, no. 32, p.13410–13415, 2015,.

DOI: 10.1039/c5nr03034j

[14] D. Valtakari, J. Liu, V. Kumar, C. Xu, M. Toivakka, and J. J. Saarinen, Conductivity of PEDOT:PSS on Spin-Coated and Drop Cast Nanofibrillar Cellulose Thin Films,, Nanoscale Res. Lett., vol. 10, no. 1, p.386, Dec. 2015,.

DOI: 10.1186/s11671-015-1093-y

[15] A. Broski, Y. Guo, W. A. Khan, and W. Li, Characteristics of PEDOT:PSS thin films spin-coated on ITO,, 2017 IEEE 12th Int. Conf. Nano/Micro Eng. Mol. Syst. NEMS 2017, p.243–247, 2017, DOI:.

DOI: 10.1109/nems.2017.8017016
