A Preliminary Investigation on Metal Injection Moulding of 316L Stainless Steel Dental Pin for Orthodontics Application

Abstract:

This research investigated metal injection moulding of dental pins for orthodontics application. 316L stainless steel powder was selected as an alternative low-cost material in comparison to the more expensive titanium alloy counterpart. The feedstock was prepared at 60% solid loading using an environmentally friendly multi-component binder. Injection moulding was operated using a four-cavity mould. The effects of moulding temperature of 250-280 °C measured at the barrel on mouldability, and specimen properties were studied. After debinding, specimens were sintered at 1250 °C for 2 hours in a hydrogen atmosphere. Experimental results indicated that injection at moulding lower temperature of 250-260 °C gave better mouldability, providing less specimen distortion and demoulding difficulty. The green density was 5.49 g/cm³, giving 93.41% theoretical density. Injection at lower temperature of 250-260 °C also provided higher sintered density and slightly lower volume shrinkage. Sintered microstructure experienced densification with small degree of isolated porosity in specimen center, however with interconnected porosity along specimen edges, responsible for 6.87 g/cm³ sintered density (86.01% theoretical density).

You might also be interested in these eBooks

The 11th Asia Conference on Mechanical and Materials Engineering

View Preview

Additive Manufacturing, Metallurgical Technologies and Materials Processing

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1110)

Pages:

15-21

DOI:

https://doi.org/10.4028/p-3XNeqK

Citation:

Cite this paper

Online since:

December 2023

Authors:

Tapany Patcharawit*, Nudthanon Chalongkittisak, Sunicha Yimyoo, Wongsakon Sawatdikomon, Monnapas Morakotjinda, Nutthita Chuankrerkkul

Keywords:

Density, Metal Injection Moulding, Microstructure, Sintering, Stainless Steel

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] W. Ryniewicz, Ł. Bojko, and A. M. Ryniewicz, The Impact of Sintering Technology and Milling Technology on Fitting Titanium Crowns to Abutment Teeth-In Vitro Studies, Materials, Vol. 15 (2022), p.5835.

DOI: 10.3390/ma15175835

Google Scholar

[2] L. Kalman, 3D Printing of a Novel Dental Implant Abutment, Journal of Dental Research, Dental Clinics, Dental Prospects, Vol.12 (2018), pp.299-303.

DOI: 10.15171/joddd.2018.047

Google Scholar

[3] S. Arango-Santander, and C. M. Luna-Ossa, Stainless Steel: Material Facts for the Orthodontic Practitioner, Revista Nacional de Odontología, Vol. 11 (2015), pp.72-81.

DOI: 10.16925/od.v11i20.751

Google Scholar

[4] S. Virdhian, S. Jamilah, S. Supriadi, and B. Suharno, Metal Injection Moulding Process Simulation for Orthodontic Bracket Application, Journal Teknologi Bahan dan Barang Teknik, Vol.7 (2017), pp.51-56.

DOI: 10.37209/jtbbt.v7i2.94

Google Scholar

[5] S. Supriadi, D. Abdussalam, T. Heriyanto, B. Irawan, B. Suharno, Transformation of Orthodontics Bracket Geometry in Metal Injection Molding Process, The 1st Materials Research Society Indonesia Conference and Congress, IOP Conf. Series: Materials Science and Engineering, Vol. 432 (2018) 012002.

DOI: 10.1088/1757-899x/432/1/012002

Google Scholar

[6] E. R. Axente, L. Benea, N. Bogatu, J-P. Celis, Susceptibility to Tribocorrosion Degradation of 304L Stainless Steel from Dental Structures in Biological Solution, Tribology International, Vol.174, (2022) 107769.

DOI: 10.1016/j.triboint.2022.107769

Google Scholar

[7] N. Chuankrerkkul, P. F. Messer and H. A. Davies, Application of Polyethylene Glycol and Polymethyl Methacrylate as a Binder for Powder Injection Moulding of Hardmetals, Chiang Mai Journal of Science, Vol. 35 (2008), pp.188-195.

Google Scholar

[8] S. Thumpudsa, P. Kakukham, C. Audpuay, T. Patcharawit, N. Chuankrerkkul, Feedstock Formulation for Metal Injection Moulding of Stainless Steel, The 12th International Conference on Thailand Metallurgy (TMETC12), Chiang Mai, Thailand, November 6-8 (2019).

Google Scholar

[9] R. M. German in, Sintering in: From Empirical Observations to Scientific Principles, Butterworth-Heinemann (2014).

Google Scholar

[10] R. M. German, Coarsening in Sintering: Grain Shape Distribution, Grain Size Distribution, and Grain Growth Kinetics in Solid-Pore Systems, Critical Reviews in Solid State and Materials Sciences, Vol. 35 (2010), pp.263-305.

DOI: 10.1080/10408436.2010.525197

Google Scholar

[11] C.H. Ji, N.H. Loh, K.A. Khor, and S.B. Tor, Sintering Study of 316L Stainless Steel Metal Injection Molding Parts using Taguchi Method: Final Density, Materials Science and Engineering A, Vol. 311 (2001), pp.74-82.

DOI: 10.1016/s0921-5093(01)00942-x

Google Scholar
