Synthesis and Characterization of NaX Molecular Sieve Zeolite Films on Ceramic Paper for Membranes

Abstract:

NaX molecular sieve films on ceramic paper prepared by in-situ hydrothermal method were investigated. The NaX zeolite seed crystals of a uniform size of 5 µm were synthesized by hydrothermal method in a mother solution having a composition of 3.5Na2O : Al2O3 : 2.1SiO2 : 500~1000 H2O. These dip-coated NaX seed crystal on ceramic paper lead to further the thickness (20 ~ 100 µm) of NaX film on the substrate at 90°C for longer 3~7 days in autoclave. Pure zeolite films consisting of a continuous intergrown of 5~ 20 µm NaX crystal have been prepared on the substrates. The zeolite films were characterized by XRD, SEM, BET and XRF.

• Periodical: Materials Science Forum (Volumes 492-493)
• Pages: 317-324
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.492-493.317
• Online since: August 2005
• Authors: Hae Jin Lee, Hyung Chul Kim, Ik Jin Kim
• Keywords: Ceramic Paper, Hydrothermal Method, Intergrowth, Membrane, NaX Zeolite, Zeolite Film

References

[1] J. F. Charnell: J. Cryst. Growth Vol. 8 (1971), p.291.

[2] W. M. Meier: Proc. Intern. Symp. Mol. Sieves, 1st, London (1968), p.10.

[3] E. F. Freund: J. Cryst. Growth Vol. 34 (1973), p.11.

[4] N. Shigemoto, S. Sugiyma, and H. Hayshi: J. Mat. Sci. Letters Vol. 13 (1994), p.660.

[5] H. C. Hu, W. H. Chen and T. Y. Lee: J. Cryst. Growth Vol. 108 (1991), p.561.

[6] W. Meise and F. E. Schwochow: Am. Chem. Soc. Vol. 169 (1973).

[7] A. F. Cronstedt: Acad. Handl. Stockholm Vol. 17 (1756), p.120.

[8] I. J. Kim and H.P. Ha: Proc. the 14th. KACG. tech. meeting and the 5th Korean-Japan EMGS. (1998), p.11.

[9] W. M. Meier: Proc. 7th lnt. Zeolite Conf. Tokyo Vol. 13 (1986).

[10] G. H. Kuehl: Molecular Sieves (Soc. Chem. Ind., London, 1968), p.85.
