Mechanics Analysis and Numerical Simulation on the Precise Forming Process of Spline Cold Rolling

Abstract:

The forming process of spline cold rolling was analyzed. The unit average pressure, contact area and rolling force in the cold rolling precision forming process were analyzed and solved. The mechanical and mathematical model has been set up on the basis of the analysis. The numerical simulation of spline cold rolling process was carried out. The results obtained by comparison of theoretical analysis, numerical simulation and experiment provide a theoretical basis for the study and application of spline cold rolling process.
