The Influence of the Solidification Process to the Dimensional Accuracy of Castings

Abstract:

The real system under consideration comprises of a solidifying casting with the casting mould, environment and other external influences. The process observed begins with the introduction of liquid metal to the channels of the runner system and filling of the mould cavity. This is connected with the contact of liquid metal with the atmosphere and also, with the walls of the mould. During the filling of the mould cavity heat transfer between the metal surface and the walls of the mould takes place (by radiation and conduction), which in practice can lead to mould cracking, and next to the formation of casting surface defects. In this stage of the process of great significance are the hydrodynamic conditions. These are dependent on the metal itself (its viscosity), and also on the runner system (rate of flow, resistances). During this time in the volume of the casting and mould, a pseudo-initial temperature fields is generated which is significant for the filling of the mould cavity and also for further cooling and solidification of the casting.

• Periodical: Materials Science Forum (Volume 649)
• Pages: 431-436
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.649.431
• Online since: May 2010
• Authors: Dániel Molnár, Jenő Dúl
• Keywords: Casting, Finite Element Model (FEM), Residual Stress, Simulation

References

[1] Bohdan Mochnacki, Jozef S. Suchy: �umerical methods in computations of foundry processes, Krakow, (1995).

[2] Christoph Honsel: Die Berechnung von Wärme- und Eigenspannungen infolge von Abkühlprozessen mit der Methode der tangentialen Steifigkeiten, Dissertation, Aachen, (1992).

[3] Konrad Weiß: Temperaturfeldberechnung bei Erstarrungsvorgängen unter Berücksichtigung des Einfüllvorganges, Dissertation, Aachen, (1986).

[4] Information on http: /www. rwp-simtec. de.

[5] SIMTEC/WinCast User's Manual, RWP-Lizenz, Version 2003, Roetgen, Germany.

[6] Christoph Honsel: How Simulation works, Casting Simulation Background and Examples, World Foundrymen Organisation, (2001).
