Evaluation of Hexahedral Mesh Quality for Finite Element Method in Electromagnetics

Abstract:

We have previously proposed an automatic hexahedral mesh generator. It is necessary to understand about the quality and characteristic of the generated mesh to perform hexahedral edge finite element analysis in electromagnetic. Therefore, we have compared high-quality meshes with poor-quality meshes, and investigated about the factors that affect the accuracy and the computation time. In addition, we investigated about the effect of the templates used in the proposed method. We will conclusively apply the result to improving the automatic hexahedral mesh generator.

• Periodical: Materials Science Forum (Volume 670)
• Pages: 318-324
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.670.318
• Online since: December 2010
• Authors: Y. Motooka, So Noguchi, H. Igarashi
• Keywords: Finite Element Model (FEM), Hexahedral Mesh, Mesh Evaluation

References

[1] S. Nagakura, S. Noguchi and H. Yamashita, Automatic Hexahedral Mesh Generation for FEA Using Shape Recognition Technique and Tree Method, IEEE Trans. on Magnetics, 38(2), 417-420 (2005).

DOI: 10.1109/20.996111

[2] H. Fujimori, S. Noguchi, H. Igarashi and H. Yamashita, An Automatic Hexahedral Mesh Generation to Control Shape of Elements, IEEE Trans. on Magnetics, 43(4), 1505-1508 ( 2007).

DOI: 10.1109/tmag.2007.891437
