Design and Optimization of UAQ4 Experimental Maglev Module

Abstract:

This paper presents the design of a novel superconducting levitated module for UAQ4 train whose feasibility has been successfully tested and confirmed in laboratory. The work concept of self-balancing “V” shaped levitation module is described and the results of levitation tests performed using a measurement set up are discussed. Lastly the levitation module performances are also carried out using numerical finite element analyses by varying the sideslip angle of the module and work system configuration.

• Periodical: Materials Science Forum (Volume 670)
• Pages: 42-47
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.670.42
• Online since: December 2010
• Authors: Gino D'Ovidio, Francesco Crisi, Giovanni Lanzara
• Keywords: Levitation, Optimization Technique, Permanent Magnet, Superconductivity

References

[1] L. Schultz et al. IEE Trans. Appl. Supercond. 15(2), (2005) 2310.

[2] In-Kun Kim et al. General Atomics Urban Maglev Technology Development Maglev'2002 Lousanne, Switzerland (2002).

[3] Wang J. et al., (2002) The first man-loading high temperature superconducting Maglev test vehicle in the world Physica C: Superconductivity and its applications 378, 809-814.

DOI: 10.1016/s0921-4534(02)01548-4

[4] D'Ovidio G. - Crisi F. - Navarra A. - Lanzara G. Lift and Guidance Forces by Using Iron-magnetic Track with Side Rims and Passive HTC Superconducting Plate: Experimental Analyses, Journal of Materials Processing Technology Volume 181, Issues 1-3, pp.18-24, Elsevier Edr, January (2007).

DOI: 10.1016/j.jmatprotec.2006.03.047

[5] D'Ovidio G. - Crisi F. - Lanzara G. On the Magnetic Resistance of YBaCuO Bulk Superconductor Dynamically Interacting with Troubled Flux of Iron-homopolar Magnetic Track, Journal of Optoelectronics and Advanced Materials Vol. 10, Issue 5, pp.1011-1016, May (2008).

[6] D'Ovidio G. - Lanzara G. - Crisi F. A "V" Shaped Superconducting Levitation Module for Lift and Guidance of a Magnetic Transportation System, Journal of Physica C: Superconductivity and its applications, Vol. 468, Issue 1, pp.1036-1040, Elsevier Edr., July (2008).

DOI: 10.1016/j.physc.2008.05.154

[7] G. D'Ovidio, F Crisi, A. Navarra, G. Lanzara G. IEE Journal Transaction on Industry Application. Vol. 126, No. 10, (2006) 1336-1340.

[8] G. D'Ovidio, F Crisi, A. Navarra, G. Lanzara G. Physica C 449, (2006) 15-20.

[9] G. D'Ovidio, F Crisi, A. Navarra, G. Lanzara G. Journal of Materials Processing Technology Vol. 181, Issues 1-3, (2007) 18-24.
