Si-B Co-Deposition Coatings on an Nb Silicide Based Ultrahigh Temperature Alloy Prepared by Pack Cementation Technique

Abstract:

In order to improve the oxidation resistance of silicide coatings on an Nb silicide based alloy, Si-B co-deposition coatings were prepared at 1150°C for 8 h by using pack mixtures containing different amounts of B powders. The microstructural characteristics of the coatings were studied. The results showed that all coatings had a triple-layer structure. The middle layers of all coatings were composed of (Nb,X)Si₂ (X represents Ti, Cr and Hf elements) and the inner layers of all coatings were composed of (Nb,X)₅Si₃, but the outer layers of the coatings had different phase constituents and morphologies when the amount of B powders in the pack mixture changed. When the amount of B powders in the pack mixture ranged from 0.5 wt% to 12 wt%, the outer layers were composed of (Nb,X)B_2­, with a few CrB₂ particles. When the amount of B powders in the pack mixture was in the range of 0.05~0.1 wt%, the outer layers were composed of (Nb,X)B₂. However, when the amount of B powders in the pack mixture was in the range of 0.02~0.03 wt%, the outer layers were composed of (Nb,X)Si₂, with needle-like (Nb,X)B₂ particles dispersed in it.

• Periodical: Materials Science Forum (Volume 686)
• Pages: 630-636
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.686.630
• Online since: June 2011
• Authors: Yu Zhang, Xi Ping Guo
• Keywords: Nb Silicide Based Alloy, Pack Cementation, Si-B Co-Deposition Coatings

References

[1] M.G. Mendiratta, D.M. Dimiduk: Metall. Trans. A Vol. 24A (1993), p.501.

[2] M.G. Mendiratta, J.J. Lewandowski: Metall. Trans. A Vol. 22A (1991), p.1573.

[3] M.R. Jackson, B.P. Bewlay and J.C. Zhao, U.S. Patent 6, 428, 910. (2002).

[4] P.R. Subramanian, M.G. Mendiratta: JOM Vol. 48 (1996), p.33.

[5] X.P. Guo, L.X. Zhao and P. Guan et al: Mater. Sci. Forum Vol. 561-565 (2007), p.371.

[6] R.O. Suzuki, M. Ishikawa and K. Ono: J. Alloys Compd Vol. 336 (2002), p.280.

[7] K. Tatemoto, Y. Ono: J. Phys. Chem. Solids Vol. 66 (2005), p.526.

[8] M. Vilasi, M. Francois and R. Podor: J. Alloys Compd Vol. 264 (1998), p.244.

[9] S. Majumdar, P. Sengupta and G.B. Kale: Surf. Coat. Technol Vol. 200 (2006), p.3713.

[10] L.X. Zhao, X.P. Guo: Nonferrous Met Vol. 17 (2007), p.596.

[11] B.V. Cockeram: Surf. Coat. Technol Vol. 76-77 (1995), p.20.

[12] Y. Wang, X.P. Guo: Acta Metall. Sin. Vol. 46 (2010), p.506.

[13] D.B. Borisov, L.V. Artyukh: Powder Metall. Met. Ceram Vol. 46 (2007), p.42.

[14] Y.B. Kuz'ma, V.S. Telegus: Poroshkovaya Metallurgiya, Vol. 77 (1969), p.79.

[15] H. Liang, Y. Chang: Intermetallics Vol. 7 (1999), p.561.

[16] C. Milanese, V. Buscaglia and F. Maglia et al: Acta Mater Vol. 51 (2003), p.4837.

[17] K. Mahdouk, J. C. Gachon: J Alloys Compd Vol. 321 (2001), p.232.

[18] A. Hellwig, M. Palm, G. Inden: Intermetallics Vol. 6 (1998), p.79.

[19] T. Qi, X.P. Guo: J. Inor Mater Vol. 24 (2009), p.1119.

[20] G. Shao: Intermetallics Vol. 12 (2004), p.655.

[21] N. David, Y. Cartigny: Intermetallics Vol. 14 (2006), p.46.
