Qualitative Analysis and Study the Workpiece Shearing Surface Quality of Fine-Blanking with Negative Clearance

Abstract:

The workpieces of fine blanking with negative clearance were obtained through the fine-blanking with negative clearance processing experiment. The fractography photographs of workpieces shearing surface were scanned by scanning electron microscope (SEM), and the characterization parameters and quality standard of workpieces shearing surface with negative clearance were analyzed in the processing of blanking. According to the characterization parameters and quality standard of workpieces shearing surface with negative clearance, the workpiece with the length ratio of burnish band, deflection error, rollover error and blanking burr were analyzed qualitative. The findings have a certain reference value to the blanking related profession.
