Study on FEM Numerical Simulation Method for the Welding Distortion

Abstract:

The control of welding distortion during assembly process is very important. At present, there are mainly two numerical simulation methods for the welding distortion which are thermo-elastic-plastic finite element method and its simplified approach of inherent strains. At first, taking T-joint as an example, the welding distortions were computed using two methods mentioned above. Based on thermo-elastic-plastic finite element method, welding process was simulated by life and death element, moving heat source and transient state thermal field etc. Then, the welding distortion was calculated by inherent strains method after thermo-elastic-plastic computation. It was concluded from the comparison that the simulation results by using the two methods are consistent. Therefore, the inherent strains method can be conveniently and economically applied to prediction of structural welding distortion in engineering. Applied the inherent strains method, welding deformation was predicted for the bogie frame side beam of high speed train. According to the deformation results from the finite element analysis, the welding deformation of the bogie frame side beam was lager than the tolerance of quality and in reasonable agreement with the experimentally determined distortion values. The work in this paper indicated that the inherent strains method was effective to predict the welding deformation so as to control the welding quality in large complex structures, such as the bogie frame of railway vehicle. Key words: welding distortion; thermo-elastic-plastic method; inherent strains approach; numerical simulation; bogie frame;

• Periodical: Materials Science Forum (Volumes 704-705)
• Pages: 1316-1321
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.704-705.1316
• Online since: December 2011
• Authors: Yao Hui Lu, Xing Wen Wu, Jing Zeng, Ping Bo Wu
• Keywords: Bogie Frame, Inherent Strains Approach, Numerical Simulation, Thermo-Elastic-Plastic Method, Welding Distortion

References

[1] Junmei Chen, Hao Lu, Jianhua Wang, Weixin Chen, Dajun Hao. Prediction of Welding Deformation of Underframe[J], Journal of Shanghai Jiao Tong University(Sicence), 2004, 10~14.

[2] Xitang Tian. Welding Structure. Bei Jing: China Machine Press, (1981).

[3] Ueda Yukio, Yuan MG. Prediction of Residual Stresses in Butt Welded Plates Using Inherent Strainss [J]. Eng Mater Technol , 1993. 115(4): 417~23.

DOI: 10.1115/1.2904240

[4] Jianhua Wang, Xinhai Qi, Xiaomin Zhong, Ueda Yukio, Murakawa Hidekazu. Three Dimensional Simulation of Welding Deformations by FEM[J]. Journal of ShangHai JiaoTong University, 1994, 28(6): 59~65.

[5] Jianhua Wang, Xinhai Qi, Xiaomin Zhong: 3-D Simulation of Transient Welding Temperature Fields by FEM[J]. Journal of ShangHai JiaoTong University, 1993, 3(30): 120~125.

[6] Yanxia Bi. Numerical Simulation of Welding Temperature Field and Stress Field of T-joint. Zhejiang University, (2007).

[7] D. Radaj. Heat Effects of Welding Residual Stress Distortion [M]. Bei Jing: China Machine Press, 1997: 189~205.

[8] Ueda Yukio , Yuanmin Gang. Predicting Method of Welding Residual stress Using source of Residual Stress (Report III): Prediction of Residual Stress in T-and I-joints Using Inherent Strains. Transaction of JWRI . 1993. 22(1): 157-168.

DOI: 10.1080/09507119209548183

[9] Dean Deng, Wei Liang, Hidekazu Murakawa. Determination of Welding Deformation In Fillet-welded Joint by Means of Numerical Simulation and Comparison with Experimental Measurements. Journal of Materials Processing Technology, 183 (2007) : 219~225.

DOI: 10.1016/j.jmatprotec.2006.10.013

[10] Dean Deng, Hidekazu Murakawa. FEM Prediction of Buckling Distortion Induced by Welding in Thin Plate Panel Structures. Computational Materials Science, 43 (2008): 591~607.

DOI: 10.1016/j.commatsci.2008.01.003

[11] Ueda YN, Ma X. Measuring Method of Three Dimensional Residual Stress With Aid of Distribution Function of Inherent Strains. Trans Jpn Weld Res Inst, 1994, 23(1): 123~30.

[12] Rui Wang, Jianxun Zhang, Hisashi Serizawa, Hidekazu Murakawa. Study of Welding Inherent Deformations in Thin Plates Based on Finite Element Analysis Using Interactive Substructure Method[J]. Materials and Design, 30 (2009): 3474~3481.

DOI: 10.1016/j.matdes.2009.03.015

[13] Xiaofang Cui, Jun Ma, Wenzhong Zhao: Numerical Simulation Study of Welding Deformation in the Bogie Frame of the High-speed Locomotive[J]. Journal of the China Railway Society, 2004, 3(26): 31~35.
