Analysis on Characteristic Features of L-Mode Guided Wave in Tube Testing

Abstract:

Applications of long range ultrasonic testing are on cylindrical products(pipes and tubes) and planar products(plates and sheets).Guided wave testing using circumferential and longitudinal modes are getting more and more importance as there are huge requirements for testing pipes and tubes in power generators, Chemical plants, steam generators etc.. There will be infinite number of modes with charectestic propagation and wave structure. This propagation characteristic and wave structure plays a major role in deciding its suitability for use in specific application. It is highly essential to use mode control and to understand the generated modes and its characteristics based on which only testing adequacy can be evaluated. In this paper the characteristic features of L-mode generated using a source design parameter for tube testing are explained. The dispersion characteristic of L-mode are discussed using constructed Dispersion Curves, phase and group velocity, its multiple defect detection capability, pulse shape and amplitude dynamics with propagation range and inclination. The details of controlled experiment conducted and the observations are discussed. The derived inferences are explained based on the applicable particle displacement equations and dispersion characteristic equations.

• Periodical: Materials Science Forum (Volume 710)
• Pages: 581-587
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.710.581
• Online since: January 2012
• Authors: S. Adalarasu
• Keywords: Design Parameter, Displacement, Group Velocity, Modes, Phase Velocity, Wave Structure

References

[1] S. Adalarasu, " Dispersion and its implications on flaw detection using guided waves" Insight Vol 47, 2005, BINDT, England.

DOI: 10.1784/insi.47.5.289.65057

[2] Li and J.L. Rose ," Angular profile turning of guided wave in hollow Cylinders using a circumference phased array", IEEE Transactions and Frequency control, 2002: 49(12); 1720-9

DOI: 10.1109/tuffc.2002.1159849

[3] P. Wilcox "The effect of dispersion on long-range inspection using ultrasonic guided waves" NDT&E International 34 (2001) 1 -9, Elsevier Science Ltd.

DOI: 10.1016/s0963-8695(00)00024-4

[4] Tribikram Kundu, "Ultrasonic Non destructive evaluation", CRC Press, Washington. D.C, USA. P311-360

[5] J.J. Ditri. "Utilization of guided waves for the characterization of circumferential cracks in hollow cylinder", J. Acoustic Society ..1994: 96: 1769-754

[6] Hee Don Jeong, "Detection of Defects in a Thin Steel Plate Using Ultrasonic Guided Wave", 15th WCNDT, Roma 2000.

[7] Farid Chati, " Longitudinal mode L(0,4) used for the determination of the deposit width on the wall of a pipe" NDT&E international, Volume 44, Issue 2, March2011, pp.188-194

DOI: 10.1016/j.ndteint.2010.12.001
