Technical Performance of High Pressure and High Temperature Processed TiC Ceramic Tools

Abstract:

Non-oxide covalent ceramics such as TiC and TiN display hardness and thermal stability that favor their use as cermet insert for high speed turning operations. The objective of this work was to assess the properties of the TiC combined with W-Mo as binding matrix. The cermet sintering was carried out inside a toroidal anvil type of high pressure device up to 1.0 GPa of pressure and temperatures up to 1800°C. It was found that at 1400°C the Mo reacts with TiC forming Mo₂C while at 1800°C the reaction with W forms WC. Moreover, the cermets density reaches 98% of the theoretically calculated value with strength of 942 MPa and Rockwell A hardness of 94. Efficient turning parameters are reported for machining operation using these cermets as tools insert.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 727-728)

Pages:

1048-1052

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.727-728.1048

Citation:

Cite this paper

Online since:

August 2012

Authors:

Guerold Sergueevitch Bobrovinitchii, Ana Lucia D. Skury, Sérgio Neves Monteiro, Márcia G. Azevedo

Keywords:

Ceramic, Diamond Tool, Hardness

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y.J. Park, S.W. Kim, S. Kang, Volume 291, Issues 1-2, 2000, pp.198-206.

Google Scholar

[2] Mari D, Gonseth DR. A new look at carbide tool life. Wear, 1993; 165: 9–17.

DOI: 10.1016/0043-1648(93)90366-t

Google Scholar

[3] H. Suzuki, K. Hayashi and Y. Taniguchi, Progress and present states for TiC based cermets. Trans Jpn Int Met, 22 (1983), p.312–319.

Google Scholar

[4] P. Lindahl, P. Guatafson, U. Rolander, L. Stals and H. -O. Andrén, Microstructure of model cermets with high Mo or W content. Int J Refract Met Hard Mater, 17 (1999), p.411–421.

DOI: 10.1016/s0263-4368(99)00032-3

Google Scholar

[5] H. Doi, Advanced TiC and TiC–TiN based cermets Proceedings of the second international conference of science hard materials, Adam Hilger Ltd., England (1984), p.489–523.

Google Scholar

[6] N. Liu, Y.D. Xu, Z.H. Li, M.H. Chen, G.H. Li and L.D. Zhang, Influence of molybdenum addition on the microstructure and mechanical properties of TiC-based cermets with nano-TiN modification. Ceram Int, 29 (2003), p.919–925.

DOI: 10.1016/s0272-8842(03)00046-4

Google Scholar

[7] D. Mari, S. Bolognini, G. Feusier, T. Viatte and W. Benoit, Experimental strategy to study the mechanical behaviour of hardmetals for cutting tools. Int J Refract Met Hard Mater, 17 (1999), p.209–225.

DOI: 10.1016/s0263-4368(98)00078-x

Google Scholar

[8] Bobrovnitchii, G.S., Monteiro, S.N., Tardim, R.C. Materials Science Forum Vols. 660-661 (2010) pp.854-859.

Google Scholar

[9] S. Cardinal, A. Malchère, V. Garnier, G. Fantozzi. International Journal of Refractory Metals and Hard Materials. Volume 27, Issue 3, May 2009, Pages 521-527.

DOI: 10.1016/j.ijrmhm.2008.10.006

Google Scholar
