Improving Thickness Uniformity of Ti₃Al Sheet Metal SPF by Preforming

Abstract:

Ti₃Al intermetallic alloy is a hard formed material with many advantages for aviation and aerospace applications. Superplastic forming (SPF) is an ideal process for Ti₃Al alloy to form sheet metal component. The thickness distribution of U cross-section circular parts, which were superplastically formed in two different female die cavity, were predicted by FEM software. According to female die forming thickness distribution, preforming die cavity was designed and was optimized by FEM software. Superplastic bugling tests with and without preforming were carried out. The thickness of parts were measured and compared with predictions by FEM software. The results showed that preforming can promote thickness uniformity efficiently in female die forming. In this experiment, the thickness difference range of the part formed with preforming reduced 75.8% compared with part formed without preforming.

• Periodical: Materials Science Forum (Volume 735)
• Pages: 130-135
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.735.130
• Online since: December 2012
• Authors: Hui Yuan Xu, Rong Xia Zhang, Yuan Song Zeng, Jia Jia Liu
• Keywords: SPF with Preforming, Thickness Uniformity, Ti₃Al

References

[1] S. Djanarthany, J.-C. Viala, J. Bouix, An overview of monolithic titanium aluminides based on Ti3Al and TiAl, Materials Chemistry and Physics 72 (2001) 301–319

DOI: 10.1016/s0254-0584(01)00328-5

[2] Y. Rosenberg, A.K. Mukherjee. The superplastic properties of a Ti3Al-Nb alloy Materials Science and Engineering A192/193 (1995) 788-792

DOI: 10.1016/0921-5093(95)03315-7

[3] Liu Yingying，Yao Zekun，Guo Hongzhen，Progress in studying on superplasticity of Ti3Al intermetallic compound, Journal of Materials Engineering 4(2008) 65-69

[4] Wang Weiying，Zhang Zhongyuan，Li Jingyi，Predicting of thickness distribution of thin components by superplastic forming, Forging & Stamping Technology 6 (1998) 35-39

[5] Jun Chen, Yong Wang, Haibo Li, Study of the Sandwich Sheet Metal Cup Drawing Characteristics. Proceeding of the 2008 International Manufacturing Science and Engineering Conference, 2008, pp.73-78

DOI: 10.1115/msec_icmp2008-72415

[6] Engenio Onate, The Finite Element Method in Industrial Forming Process, NUMIFORM2010, Proceedings of the 10th International Conference, (2010)15-17

[7] S.George Luckey, Peter A. Friedman, Hot Draw Mechanical Preforming of an Automotive Door Inner Panel, ASME 2008 International Conference on Manufacturing Science & Engineering, pp.561-570

DOI: 10.1115/msec_icmp2008-72133
