Structural-Mechanical Control of Bypass Reactivity in LISB for Space Application Using Alloys with Shape Memory Alloys

Abstract:

Keywords: Lithium-ion storage battery (LISB), bypass device, shape memory effect (SME) thermal treatment, reactivity, reliability Abstract. Deformation and strength characteristics of a thermal drive spring made of alloy with shape memory effect (SME) оn the base of TiNi in bypass device (BD) of Lithium-ion storage battery (LISB) for space application were investigated. A technique was developed for this spring thermal preparation for a certain magnitude of shape memory deformation, due to which during reverse martensite transformation a spring generates reactive force, sufficient for BD operation. It allowed to develop small-sized multiple action BDs for LISBs intended for “Glonass-K” spacecrafts. Study of technological and operational factors’ impact proved high level of BD failure-free operation.

• Periodical: Materials Science Forum (Volumes 738-739)
• Pages: 601-606
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.738-739.601
• Online since: January 2013
• Authors: N.A. Protsenko, Zhesfina Blednova
• Keywords: Bypass Device, Lithium-Ion Storage Battery (LISB), Reactivity, Reliability, Shape Memory Alloy (SMA), Shape Memory Effects (SME), Thermal Treatment

References

[1] Shape Memory Materials / Ed. by K. Otsuka and C.M. Wayman. Cambridge: Cambridge University Press, 1999. 284 p.

[2] Materials with shape memory effects. Reference publication. Under the editorship of V.А Likhachev., V. 1. Publishing house NIIH, St.-Petersburg, 1997 (in Russian).

[3] Zh.М. Blednova, V.Y. Lapshin, N.А. Protsenko. Thermal processes simulation in LISBs for space application in case of one cell failure, Proceedings of Academenergo, № 2 (2011) 117-127 (in Russian).

[4] Zh.М. Blednova, V.V. Galkin, М.I. Chaevsky, I.S. Мyshevsky and N.А. Protsenko, RF Patent 2392494 (2010).

[5] Zh.М. Blednova,, V.V. Galkin, N.А. Protsenko. Bypass device, using shape memory effect materials to ensure LISB operability for space application, Polyot, № 6, (2011) 58-60 (in Russian).

[6] N.N. Resnina, S.P. Belyaev, A.V. Sibirev. Transformation plasticity and shape memory effects in TiNi alloy after low-temperature treatment, Journal of Technical Physics. V. 81, № 4 (2011) 144-147.

DOI: 10.1134/s1063784211040268

[7] O.I. Krakhin, А.П. Smiths, M.G. Kosov. Alloys with memory. Bases of designing of designs. Stary Oskol, TNT, 2011 (in Russian).

[8] V.V. Galkin, Zh.М. Blednova, N.А. Protsenko. Reliability and life time estimation of LISB bypass device with a spring made of SME materials for space application, taking into account technological and operational factors, Polyot, № 5 (2012) 20-27 (in Russian).
