Influences of Excess PbO on Optical Properties and Microstructures of La Modified 0.75Pb (Mg_1/3Nb_2/3)O₃-0.25PbTiO₃ Electro-Optic Transparent Ceramics

Abstract:

La-modified 0.75Pb (Mg_1/3Nb_2/3)O₃-0.25PbTiO₃(PLMNT) electro-optic (EO) transparent ceramics were synthesized through a columbite precursor method. Excess PbO (10, 15 and 20 mol %) was added to study the effect on the transparency, electro-optic effect, and microstructures of PLMNT transparent ceramics. The phase structure of different samples can be identified as single perovskite structure with no second phase detected. The average grain size increased as the concentration of excess PbO increased from 10 mol% to 20 mol%. On the contrary, the transparency decreased with the increase of the concentration of excess PbO. When the concentration of excess PbO was 10 mol%, the transmittance was about 62% at 632.8nm. The EO coefficient was calculated through measuring the birefringence as a function of electric field. The EO coefficient increased with the increase of the concentration of excess PbO and the maximum EO coefficient reached 40.6×10^-16(m/V)² when the excess PbO was 20 mol%.

You might also be interested in these eBooks

Advances in Functional and Electronic Materials

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 745-746)

Pages:

555-559

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.745-746.555

Citation:

Cite this paper

Online since:

February 2013

Authors:

Wen Long Ji, Xi Yun He, Wen Xiu Cheng, Ping Sun Qiu, Xin Sen Zheng

Keywords:

Electro-Optic Effect, Excess PbO, PLMNT Transparent Ceramics, Transmittance

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K. Uchino, Electro-optic Ceramics and their Display Applications, Ceramics International. 21 (1994) 309-315.

DOI: 10.1016/0272-8842(95)96202-z

Google Scholar

[2] H. Jiang, Y.K. Zou, Q. Chen, K.K. Li, R. Zhang, Y. Wang, et al., Transparent Electro-Optic Ceramics and Devices, Proceedings of SPIE 5644 (2005) 380.

Google Scholar

[3] J. Zhang, S. Mo, H. Wang, S.X. Zhen, H. Chen, C. Yang, Microstructure and electrical properties of PLZT ceramics from Pb3O4 as the lead source, Journal of Alloys and Compounds. 509(6) (2011) 2838-2841.

DOI: 10.1016/j.jallcom.2010.11.135

Google Scholar

[4] S. Snow, G. Improvements in Atmpsphere Sintering of Transparent PLZT Ceramics, journal of the American Ceramic Society. 56(9) (1973) 479-480.

DOI: 10.1111/j.1151-2916.1973.tb12528.x

Google Scholar

[5] G.H. Haertling, Improved Hot-Pressed Electrooptic Ceramics in the (Pb, La)(Zr, Ti)O3 system, journal of the American Ceramic Society. 54(6) (1970) 303-309.

DOI: 10.1111/j.1151-2916.1971.tb12296.x

Google Scholar

[6] H.F. Zhai, R.L. Tang, A.D. Li, H.R. Guo, Y.D. Xia, D. Wu, Preparation and Characterization of Relaxor Ferroelectric 0. 65 Pb(Mg1/3Nb2/3)O3–0. 35PbTiO3 by a Polymerizable Complex Method, Journal of the American Ceramic Society. 92(6) (2009).

DOI: 10.1111/j.1551-2916.2009.03004.x

Google Scholar

[7] L. Cao, X. Yao, Z. Xu, Effect of Ta substitution on microstructure and electrical properties of 0. 80 Pb(Mg1/3Nb2/3)O3–0. 20PbTiO3 ceramics, Ceramics International. 30(7) (2004) 1369-1372.

DOI: 10.1016/j.ceramint.2003.12.104

Google Scholar

[8] B. Sahoo and P.K. Panda, Effect of CeO2 on dielectric, ferroelectric and piezoelectric properties of PMN–PT (67/33) compositions, Journal of Materials Science. 42(13) (2007) 4745-4752.

DOI: 10.1007/s10853-006-0828-7

Google Scholar

[9] J.C. Bruno, A.A. Cavalheiro, M.A. Zaghete, M. Cilense, J.A. Varela, Structural effects of Li and K additives on the columbite precursor and 0. 9PMN–0. 1PT powders, Materials Chemistry and Physics. 84(1) (2004) 120-125.

DOI: 10.1016/j.matchemphys.2003.11.014

Google Scholar

[10] N. Zhong, X.L. Dong, D.Z. Sun, P.H. Xiang, H. Du, Electrical properties of Pb(Mg1/3Nb2/3)O3–PbTiO3 ceramics modified with WO3, Materials Research Bulletin. 39(2) (2004) 175-184.

DOI: 10.1016/j.materresbull.2003.10.007

Google Scholar

[11] W. Ruan, G.R. Li, J.T. Zeng, J.J. Bian, L.S. Kamzina, H.R. Zeng, et al., Large Electro-Optic Effect in La-Doped 0. 75 Pb(Mg1/3Nb2/3)O3–0. 25PbTiO3 Transparent Ceramic by Two-Stage Sintering, Journal of the American Ceramic Society. 93 (8) (2010).

DOI: 10.1111/j.1551-2916.2010.03675.x

Google Scholar

[12] Y.C. Zhang, W.N. Ye, Z.Z. Yang, C.J. Lu, L.H. Xia, Effect of excess Pb on formation of perovskite-type 0. 67 Pb(Mg1/3Nb2/3)O3–0. 33PbTiO3 powders synthesized through a sol–gel process, Journal of Materials Science: Materials in Electronics. 22 (1) (2010).

DOI: 10.1007/s10854-010-0090-2

Google Scholar

[13] Y.C. Zhang, Z.Z. Yang, W.N. Ye, C.J. Lu, L.H. Xia, Effect of excess Pb on microstructures and electrical properties of 0. 67Pb(Mg1/3Nb2/3)O3–0. 33PbTiO3 ceramics, Journal of Materials Science: Materials in Electronics. 22 (3) (2010) 309-314.

DOI: 10.1007/s10854-010-0134-7

Google Scholar

[14] L.S. Kamzina, R. Wei, G. Li, J. Zeng, A. Ding, Electro-optical properties of PMN-xPT compounds: Single crystals and transparent ferroelectric ceramic, Physics of the Solid State. 52 (10) (2010) 2142-2146.

DOI: 10.1134/s1063783410100203

Google Scholar
