The Effect of Working Pressure on the Composition and Optical Properties of TiO₂ Films Bombarded by N Ion Beams

Abstract:

N-doped TiO2 films were prepared by using N ion beams to bombard TiO2 films surface. By controlling the metal ultrahigh vacuum gat valve, only the N ion beams working pressure was adjusted from 0.1 to 0.9 Pa, with the step size of 0.2 Pa. The composition, chemical bond structure, and optical properties of N-doped TiO2 films were investigated. The result indicated that with increasing the ion source working pressure, more N ions were generated and bombarded with the surface TiO2 films, which could result in more N ions were doped into the films. So with increasing the ion source working pressure from 0.1 to 0.9 Pa, the N/Ti and O/Ti atom ratio increased and decreased monotonously from 0.37 to 0.49 and 1.49 to 0.61, respectively. Meanwhile, because of more N doped into films, the mean absorbency of N doped TiO2 films in the visible range also increased monotonously from 4.8% to 45.8%.

You might also be interested in these eBooks

Advanced Materials Science and Technology (IFAMST-8)

View Preview

Info:

Periodical:

Materials Science Forum (Volume 750)

Pages:

302-305

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.750.302

Citation:

Cite this paper

Online since:

March 2013

Authors:

Ting Ting Yao, Hong Lin Liu, Wan Yu Ding, Dong Ying Ju, Wei Ping Chai

Keywords:

Ion Source, N Doped TiO₂, Optical Property, XPS

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] R. Asahi, T. Morikawa, T. Ohwaki, K. Aoki, and Y. Taga: Science, Vol. 293 (2001), p.269.

Google Scholar

[2] C. Zhang, W. Y. Ding, H. L. Wang, W. P. Chai, and D. Y. Ju: J. Environ., Sci. Vol. 21 (2009), p.741.

Google Scholar

[3] W. Y. Ding, H. L. Wang, Z. Miao, J. J. Zhang, W. P. Chai: Acta Phys. Sin., Vol. 58 (2009), p.432.

Google Scholar

[4] Information on http: /www. hbcpnetbase. com.

Google Scholar

[5] J. F. Moulder, W. F. Stickle, P. E. Sobol K. D. Bomber, in: Handbook of X-ray photoelectron spectroscopy, edited by J. Chastain, R. C. King, Physical Electronics, Inc. (1995).

Google Scholar

[6] W. Z. Tang: The theory and technology of the thin film production (Melallurgical Industry Press, China 2003).

Google Scholar
